External Locator - Front (Audio "DJ") & Rear Views
Figure 2
Front Views
1.
Audio "DJ" Power
Button
2.
Volume Down
3.
Volume Up
4.
Repeat
5.
LED Display
6.
Previous Track
7.
Next Track
8.
Play/Pause
9.
Stop (Press Twice To
Eject The CD/DVD)
10. Repeat Mode
Indicator
11. Track Indicator
12. Time Indicator
13. Disc Indicator
Figure 3
Rear Views
1.
Vent/Fan Intake/Out-
let
2.
S/PDIF-Out Jack
3.
Line-In Jack
4.
2 * USB 2.0 Ports
5.
DVI-Out Port
6.
TV-In(Enabled With
TV Tuner Only)
7.
RJ-11 Phone Jack
8.
RJ-45 LAN Jack
9.
S-Video-Out Jack
10. DC-In Jack
11. Serial Port
1 - 6 External Locator - Front (Audio "DJ")& Rear Views
1
2
3
4
11
10
1
3
2
4
5
6
13
12
5
6
7 8
9
10
7
8
9
11
