Removing the Keyboard
1. Turn off the computer, and remove the battery
2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you
may need to use a small screwdriver to do this).
3. Carefully lift the keyboard
4
4. Disconnect the keyboard ribbon cable
5. Carefully lift up the keyboard
a.
1
b.
4
Keyboard Tabs
(page 2 -
5).
up, being careful not to bend the keyboard ribbon cable
from the locking collar socket
5
(Figure
d) off the computer.
4
c.
2
3
4
d.
(Figure
11c).
5
.
6
5
6
4
Removing the Keyboard 2 - 15
Disassembly
Figure 11
Keyboard Removal
a. Press the three latches
to release the keyboard.
b. Lift the keyboard up.
c. Disconnect
the
cable
from the locking collar.
d. Remove the keyboard.
Re-Inserting the Key-
board
When re-inserting the
keyboard firstly align
the five keyboard tabs
at the bottom
(Figure
11b) at the bottom of
the keyboard with the
slots in the case.
4. Keyboard
