Removing the Battery

1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow, and hold it in place.
1
3. Lift the battery out at point
2
Lift the battery (Figure c) up and out off the computer.
4. 4
a.
c.
.
, in the direction of the arrow
3
b.
1
2
4
Battery Removal
a. Slide the latch and hold
in place.
b. Lift the battery in the di-
rection of the arrow.
c. Lift the battery out.
3
4. Battery
Removing the Battery 2 - 5
Disassembly
Figure 1
