External Locator - Bottom View

Figure 6
Bottom View
1. Vent/Fan Intake/
Outlet
2. Video Card Cover
3. Battery
4. Optical Device
Release Latches
5. HDD / RAM Bay
Cover
6. Infrared &
Consumer
Infrared
Transceiver
Overheating
To prevent your com-
puter from overheating
make sure nothing
blocks the vent/fan in-
takes while the com-
puter is in use.
