Removing the Optical (CD/DVD) Device

1. Turn off the computer, and turn it over and remove the battery.
2. Slide the latch in the direction of the arrow, and hold it in place.
1
3. Eject the optical device by carefully sliding the latch
3
4. Reverse the process to install the new device.
.
a.
2
in the direction of the arrow.
2
1
3
Removing the Optical (CD/DVD) Device 2 - 11
Disassembly
Figure 7
Optical Device
Removal
a. Slide the latch at point 1
in the direction of the ar-
row, and hold it in place .
Push the optical device
out off the computer at
point 2.
3. Optical Device
