Converting 2.6 Gb Drive Jukeboxes to 5.2 Gb Drive Jukeboxes
Install the Replacement Interface PCA
Install the Replacement Interface PCA
NOTE
Note the interface cable configuration and the selection on the interface select
switch so the same configuration can be restored after replacing the interface PCA.
1. Remove the SCSI cables and power cable from the interface module.
2. Remove the four T-20 screws securing the interface module to the side of the
chassis (see Figure 3-10).
3. Disconnect the SCSI and power cables to the interface PCA.
Figure 3-10 Removing the SCSI Interface Module
3-13
