All jukeboxes of the 5.2-Gbyte generation are shipped with a full complement of 64
cartridge slots. In addition to converting the drive technology to 5.2 Gbyte capacity,
the conversion kits also provide the capability to add 32 cartridge slots to 32-slot
jukeboxes. By adding slots, the jukebox matches the configuration of the jukebox as
shipped from the factory and prepares the jukebox to upgrade to a four-drive 5.2
Gbyte drive jukebox later.
Check your conversion kit contents in the following table before you begin.
You will be using the following chapters:
•
•
•
Table 1-2 Contents of the C5131J/K/L Conversion Kits
Chapter 3 - "Converting From 2.6 Gb Disk Drives to 5.2 Gb Disk Drives"
Chapter 4 - "Downloading Firmware"
Chapter 5 - ""Verifying Jukebox Operation, Labeling, and Cleanup"
Part
5.2 Gbyte drive
interposer PCA
interface PCA
8-slot magazine
RFI clamp
EMI gasket
T-20 screws
M3x6 T-10 screws
flat cable clamp
left panel - flint grey
right panel - flint grey
Upgrades, Conversions, and Kit Contents
Part
Qty
Number
2 C1113-60008
1 C1150-60004
1 C1150-60008
8 C1100-44400
2 869623 two plates, two end clips
1 C1160-80602
6 0515-2282 extra assembly and panel
mounting screws
16 0515-2382 for mounting drives in the
drive enclosure
2 1400-0514
1 C5175-00202 C5131J & C5131L options
#700 & 726 (not labeled)
1 C5175-00204 C5131J & C5131 options
#700 & 726 (not labeled)
First Steps
Comments
