Upgrading Drives and Capacity in 5.2 Gb Drive Jukeboxes
Add Drives
Add Drives
1. Disconnect all cables from the currently installed drives to the interposer PCA.
2. Remove the two T-20 screws securing the empty drive location cover plate ( # 1
on Figure 2-2).
Figure 2-2
Removing the Drive #3 and #4 Cover Plate
2-5
