Converting 2.6 Gb Drive Jukeboxes to 5.2 Gb Drive Jukeboxes
Remove the Right, Left and Rear Panels
Remove the Right, Left and Rear Panels
WARNING
Disconnect the power cord before taking the jukebox apart to prevent possible
electrical shock.
1. Remove the right-side, left-side, and rear panels.
Figure 3-1 The Right, Left, and Rear Access Panels
3-4
• the left-side panel does not use any fastening screws
• the right-side panel has one combination slotted/Torx screw on the bottom
edge
• the rear panel has eight T-20 screws around its perimeter
