HP Surestore 100st - Archive Server Conversion Instructions page 46

Converting 2.6 Gb Drive Jukeboxes to 5.2 Gb Drive Jukeboxes
RFI Modifications (For Conversions)
Adding an RFI Cabinet Strip
NOTE You may apply the EMI gasket to the front panel either before or after you remount
the front panel on the jukebox.
1. Remove the adhesive backing on the EMI gasket.
2. Stick the EMI gasket to the center of the bottom edge of the front panel as shown
IMPORTANT
Note the orientation of the EMI gasket in the insert on Figure 3-16. The "V" shape
must point outward from the chassis.
Figure 3-16 Mounting the EMI Gasket on the Front Panel
3-20
on the left of Figure 3-16).
