HP Surestore 100st - Archive Server Conversion Instructions page 11

Part
RFI clamp
EMI gasket
T-20 screws
M3x6 T-10 screws
flat cable clamp
left panel - flint grey
right panel - flint grey
left panel - parch.white
right panel - parch
white
product label
320ex nameplate
Upgrades, Conversions, and Kit Contents
Part
Qty
Number
2 869623 two plates, two end clips
1 C1160-80602
6 0515-2282 extra assembly and panel
mounting screws
32 0515-2382 for mounting drives in the
drive enclosure
2 1400-0514
1 C5175-00202 C5132J & C5131L options
#700 & 726
1 C5175-00204 C5132J & C5131L options
#700 & 726
1 C5175-00203 C5132L #768 kit only
1 C5175-00205 C5132L #768 kit only
1 5181-9902 placed over the current
product label
1 C1160-84309 C5132J kit only
or
C1160-84310 C5132K and C5132L #726
kits only
First Steps
Comments
1-7
