Remove the Right and Left Access Panels
WARNING
Disconnect the power cord before taking the jukebox apart to prevent possible
electrical shock.
CAUTION
Do not switch off power to the jukebox until you are sure the SCSI bus is inactive.
Switching off the jukebox when the SCSI bus is active can cause data loss and/or
indeterminate bus states.
1. Turn power off.
2. Unplug the power cord from the power source.
3. Refer to Figure 2-1 for the location of the right and left panels and the mounting
Upgrading Drives and Capacity in 5.2 Gb Drive Jukeboxes
The power switch is to the right of the mailslot on Figure Figure 2-1.
screw on the right-side panel. (Right and left are as viewed from the front of the
jukebox.)
a. Remove the combination slotted/Torx screw on the bottom of the right side
panel and lift the panel off.
b. Lift the left-side panel up slightly and then rotate the panel away.
Remove the Right and Left Access Panels
2-3
