Maintaining the printer
4
5
6
7
8
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
Lift the continuous cleaning roller unit out of the printer (step 1 in Figure 4-2).
2
Figure 4-2: Lift the roller out of the printer
Slide the used sleeve off the cleaning roller spindle (step 2 in Figure 4-2). Discard
the used sleeve.
Slide a new replaceable cleaning sleeve onto the spindle (step 1 in Figure 4-3).
1
Figure 4-3: Replace the cleaning roller sleeve
Hold the replaceable cleaning roller spindle by the ends and remove the
protective cover from the sleeve (step 2 in Figure 4-3). Discard the protective
cover.
i
Avoid touching the sticky surface of the replaceable sleeve. Oils from your
fingers could reduce cleaning and could affect card quality.
Continue to hold the spindle by the ends. Replace the spindle with sleeve in the
printer (step 3 in Figure 4-3).
1
2
3
3
4-3
