Using The Printer Cleaning Card - DataCard ImageCard Select User Manual

4-4
9
10 Close the swing arm, pressing it down until the push latch clicks into place.
11 Close the printer top cover.

Using the printer cleaning card

Use the printer cleaning card when prompted or according to schedule. You can run a
printer cleaning card whenever you are not printing, whether or not you have been
prompted.
Run a printer cleaning card
E
1
2
3
4
Replace the print ribbon cartridge.
If the printer has a locking card cartridge, unlock the cartridge before removing it.
Remove the card cartridge and set it aside.
E
If the print ribbon sticks to the printer cleaning card, remove the print ribbon
and repeat this procedure with a new printer cleaning card.
Peel the protective paper backing from both sides of the printer cleaning card (see
Figure 4-4).
Figure 4-4: Printer cleaning card
Insert the printer cleaning card on the input rollers, which you can see after
removing the card cartridge (see Figure 4-5).
Figure 4-5: Insert the printer cleaning card
Start a cleaning cycle by doing one of the following:
User's Guide for ImageCard® Select™ and UltraGrafix® Select™
Maintaining the printer
