Power cord

The Select printer uses one of the following power cords:
•
•
•
•
•
•
•
•
•
•

Smart card serial cable

If the Select printer has one or more smart card modules, it uses the smart card serial
cable to connect the smart card port and the PC. The smart card serial cable is part
number 805815-001.
i
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
U.S. power cable (part number 556766-010)
Figure B-9: U.S. power cable
European power cable (part number 806842-001)
Australian power cable (part number 806842-002)
United Kingdom power cable (part number 806842-003)
Danish power cable (part number 806842-004)
Indian power cable (part number 806842-005)
Israeli power cable (part number 806842-006)
Italian power cable (part number 806842-007)
Swiss power cable (part number 806842-008)
Japanese power cable (part number 806842-009)
The smart card serial cable must be a shielded DB9 serial cable, up to 3 meters
long maximum.
Figure B-10: Smart card serial cable
B-11
