User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
Figure C-6: Settings dialog box
Select the Port Settings tab.
Select the following settings:
Setting Value
Bits per second 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
When the settings are correct, click OK to save settings and close the dialog box.
C-13
