Before you install
•

Selecting the site

After meeting general requirements, the site for the Select printer should meet the
electrical, physical, and environmental requirements of the printer. Finally, be sure to
select an appropriate site for printer supplies.

Electrical requirements

The Select printer requires the following electrical conditions for optimal performance:
•
•
The maximum input current for the Select printer is 1.4 amps at 100 VAC applied.

Physical requirements

The Select printer requires an environment that accommodates its physical
dimensions and weight.
The printer weighs between 21 and 26.5 pounds or 9.7 and 11.9 kilograms.
i
The dimensions are:
•
•
•
•
The clearance required is:
•
•
•
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
Store all supplies in a clean, cool, dry location. See "Supply roll storage" on
page B-2 for information about the storage environment for Select supplies.
90-254 VAC at 50/60 Hz (The Select printer automatically adjusts to any power
within this range.)
Single phase, 3-wire grounded receptacle only
The surface holding the printer might also need to bear the weight of other
equipment such as a PC and camera.
Depth of 17.8 inches (54.1 cm) for Select models
Depth of 24 inches (65 cm) for Select 2 models
Width of 8.8 inches (22.2 cm)
Height of 10 inches (25.4 cm)
3 inches (7.5 cm) on the left side of the printer, for access to the power switch and
for ventilation.
3 inches (7.5 cm) in back of the printer for ventilation and for clearance for cables.
10.5 inches (26.7 cm) above the printer to allow the cover to open and to change
supplies.
6-3
