Using the printer driver
•
The Printing Preferences dialog box also provides access to the About dialog box,
which shows the printer driver version.
Settings that control the non-printing operation of the printer are in the Properties
dialog box for the printer. These settings include:
•
•
E
Use the Properties dialog box
Make sure the printer power is on and the printer is connected to the PC.
1
2
3
4
5
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
Magnetic stripe encoding formats and coercivity
Port to which the printer is attached
Permissions for other users of the PC
The Select printer driver provides help for the Printing Preferences dialog box and
Windows 2000 provides help for the Properties dialog box. Help provides
information about specific settings of the Select printer driver. Help does not
include step-by-step procedures or detailed conceptual information.
Select Start from the Windows 2000 taskbar.
From the Windows Start menu, select Settings and then Printers. The Printers
window appears.
Click once on the Select printer driver icon.
Select File from the Printers menu bar, and then select Properties. The Select
Properties dialog box appears.
Figure 3-4: Select Properties dialog box, Windows 2000
Select the tab that contains the information you want to view or change.
3-7
