Datacard
CD800
Card Printer
®
User's Guide
March 2014
Part No. 527443-001 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD800 and is the answer not in the manual?

Questions and answers

Summary of Contents for DataCard CD800

  • Page 1 Datacard CD800 Card Printer ® ™ User’s Guide March 2014 Part No. 527443-001 Rev. A...
  • Page 2: Proprietary Notice

    Notice Please do not attempt to operate or repair this equipment without adequate  training. Any use, operation, or repair you perform that is not in accordance with  the information contained in this documentation is at your own risk. Proprietary Notice All drawings and information herein are the property of DataCard Corporation. All  unauthorized use and reproduction is prohibited.  Trademark Acknowledgments Datacard is a registered trademark and service mark of DataCard Corporation in  the United States and other countries. CD800 is a trademark of DataCard Corporation. Windows is a registered trademark of Microsoft Corporation.  All other product names are the property of their respective owners. Datacard Group 11111 Bren Road West Minnetonka, MN 55343‐9015 Phone: 952‐933‐1223 Fax: 952‐933‐7971 www.datacard.com ©2014 DataCard Corporation. All rights reserved. Printed in the United States of America.
  • Page 3: Compliance Statements

    Compliance Statements Liability Statement The WARNING and CAUTION labels have been placed on the equipment for your safety.  Please do not attempt to operate or repair this equipment without adequate training.  Any use, operation or repair in contravention of this document is at your own risk.  Safety All Datacard® products are built to strict safety specifications in accordance with CSA/ UL60950‐1 requirements and the Low Voltage Directive 2006/95/EC.    Therefore, safety issues pertaining to operation and repair of Datacard® equipment are  primarily environmental and human interface. The following basic safety tips are given to ensure safe installation, operation and  maintenance of Datacard® equipment.  • Connect equipment to a grounded power source. Do not defeat or bypass  the ground lead.  • Place the equipment on a stable surface (table) and ensure floors in the work  area are dry and non‐slip.  • Know the location of equipment branch circuit interrupters or circuit  breakers and how to turn them on and off in case of emergency.  • Know the location of fire extinguishers and how to use them. ABC type  extinguishers may be used on electrical fires.  • Know local procedures for first aid and emergency assistance at the customer  facility.  • Use adequate lighting at the equipment location.  • Maintain the recommended temperature and humidity range in the  equipment area. ...
  • Page 4: Regulatory Compliance

    Regulatory Compliance These notices apply to the Datacard printer and all Datacard accessory devices that  connect to the printer. FCC Notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following  two conditions: (1) This device may not cause harmful interference, and (2) this device  must accept any interference received, including interference that may cause undesired  operation. Note: This equipment has been tested and found to comply with the limits for a Class A  digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide  reasonable protection against harmful interference in a commercial installation. This  equipment generates, uses and can radiate radio frequency energy and, if not installed  and used in accordance with the instructions, may cause harmful interference to radio  communications. However, there is no guarantee that interference will not occur in a  particular installation. If this equipment does cause harmful interference to radio or  television reception, which can be determined by turning the equipment off and on, the  user is encouraged to try to correct the interference by one or more of the following  measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance  could void the user's authority to operate the equipment. Industry Canada Notice This device complies with Industry Canada licence‐exempt RSS standard(s). Operation is  subject to the following two conditions: (1) this device may not cause interference, and  (2) this device must accept any interference, including interference that may cause  undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils  radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:  (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit  accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en  compromettre le fonctionnement.
  • Page 5: Notice For Europe

    Host Device Labeling Requirement Notice To meet the FCC and Industry Canada host device labeling requirements, any host  equipment incorporating the 506241 module must include the FCC ID/IC number on the  host label as follows: Contains transmitter module IC: 889B‐506241001 where 889B‐506241001 is the module's IC certification number. Contains transmitter module FCC ID: GDI‐506241001 where GDI‐506241001 is the module's FCC ID number. Notice for Europe The EU Declaration of Conformity can be found on Datacard.com We hereby certify that this printer complies with EMC Directive2004/108/EC , R&TTE  Directive 1999/5/EC, and the EU RoHS Directive EU Directive 2011/65/EC. This printer  conforms to Class A of EN 55022 and to EN 301 489‐5. Operation of this equipment in a  residential environment may possibly cause interference. In the event of interference,  the users, at their own expense, will be required to take whatever measures are  necessary to correct the problem. Notice for China (Simplified Chinese) 为 级产 环 该产 线 这 对 Notice for Taiwan (Traditional Chinese)
  • Page 6: Notice For Japan

    Notice for Japan Japanese Voluntary Control Council for Interference (VCCI) class A statement  Korea Communications Commission (KCC) statement California Proposition 65 Compliance WARNING: This product contains chemicals, including lead, known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling.
  • Page 7 Revision Log CD800 Card Printer User’s Guide Revision Date Description of Changes March 2014 First release of this document (formerly Part No. 527248-001). Updated for CLM laminator and XPS Card Printer Driver 5.0.
  • Page 8 viii...
  • Page 9: Table Of Contents

    About this Manual______________________________________________________________ 1 Intended Audience ____________________________________________________________ 1 Technical Support ______________________________________________________________ 1 Chapter 2: About the Printer ________________________________________________________ 3 About the CD800 Card Printer ___________________________________________________ 3 Printer Components ____________________________________________________________ 3 Printer Left Side _____________________________________________________________ 4 Printer Right Side ___________________________________________________________ 5...
  • Page 10 Chapter 5: System Maintenance___________________________________________________ 29 Clean the Printer ______________________________________________________________ 29 Clean the Printhead ___________________________________________________________ 30 Run a Cleaning Card __________________________________________________________ 32 Single Hopper _____________________________________________________________ 32 Optional Multi-Hopper _____________________________________________________ 35 Prepare the Printer for Cleaning ________________________________________ 35 Clean the Printer_______________________________________________________ 36 Clean the Hopper Rollers _______________________________________________ 37 Prepare the Printer for Use ______________________________________________ 38 Chapter 6: Troubleshooting _______________________________________________________ 41...
  • Page 11 104: Critical problem ___________________________________________________ 68 105: Magstripe data error ______________________________________________ 68 106: Magstripe data not found _________________________________________ 69 107: Magstripe read data error _________________________________________ 69 108: Magstripe read no data ___________________________________________ 70 109: Print ribbon problem _______________________________________________ 70 110: Print ribbon out or missing __________________________________________ 70 111: Card not picked __________________________________________________ 71 112: Card hopper empty _______________________________________________ 71 113: Close cover to continue ___________________________________________ 71...
  • Page 12 208: L2 supply type problem ____________________________________________ 79 209: L2 supply not supported ___________________________________________ 79 210: L2 supply not identified ____________________________________________ 79 211: L1 heater problem_________________________________________________ 79 212: L2 heater problem_________________________________________________ 80 213: L1 heater sensor problem __________________________________________ 80 214: L2 heater sensor problem __________________________________________ 80 215: L1 heater roller problem ___________________________________________ 80 216: L2 heater roller problem ___________________________________________ 80 217: Debow problem___________________________________________________ 80...
  • Page 13 Laminator Setup _____________________________________________________________ A-6 Laminator Overlay Materials ______________________________________________ A-6 Serialized Overlay with Bar Code __________________________________________ A-8 Load Laminator Overlay Material__________________________________________ A-9 Card Design ___________________________________________________________ A-11 Verify Setup ____________________________________________________________ A-11 Clear Laminator Card Jam __________________________________________________ A-12 Clean the Laminator ________________________________________________________ A-13 xiii...
  • Page 15: Chapter 1: Introduction

    Chapter 1: Introduction About this Manual This manual provides user information for the CD800 Card Printer. The manual  includes: An overview of printer components and options, and a description of the  • system label. How to use the printer, including how to power the printer on and off, how to  • use the front panel and LCD menus, card processing basics, how to print a test  card, and how to load and replace supplies. How to perform routine maintenance and troubleshooting tasks.  • An additional Installation and Administrator’s Guide is available for use by  administrators or other professionals responsible for printing cards. Refer to the  Owner’s Library CD. Intended Audience The manual is intended for the printer operator who prints cards, loads and  replaces supplies, maintains the printer, and performs troubleshooting. Technical Support Contact Datacard Technical Phone Support at 1‐800‐328‐3996. CD800 Card Printer User’s Guide...
  • Page 16 Introduction...
  • Page 17: Chapter 2: About The Printer

    Chapter 2: About the Printer About the CD800 Card Printer The card printer applies images, text, and encoded data to plastic cards. It prints  full‐color and monochrome images, depending on the print ribbon installed. A busy issuance site might issue up to 10,000 cards a month. During these busy  times, the site might use more than one printer to keep up with demand. The  printer issues cards either one at a time or in batches—up to 100 cards at a time.  A 200‐card input hopper is available and can be installed without tools. In  addition, an optional multi‐hopper with six input hoppers, each with a  100‐card capacity, is available. Other options available for the card printer include magnetic stripe, smart card,  and automatic duplex modules, and a reject hopper. The configuration label on  the printer shows the options installed. Refer to “System Label” on page 10 for  more information about recognizing the factory‐installed options on your card  printer. An optional laminator also is available when you purchase your printer or  as a field upgrade (refer to "CLM Laminator" on page A‐1.) Printer Components Refer to the following to view the printer components and the different options: Printer Left Side on page 4  • Printer Right Side on page 5 • Printer with Single Input Hopper on page 6  • Printer with Optional Multi‐Hopper on page 7 • Print Ribbon Cartridge on page 8 • Printer with Optional CLM Laminator on page 9  • System Label on page 10 •...
  • Page 18: Printer Left Side

    Printer connections include: Power receptacle • USB connection • Network connection • Printer Access Cover The lock provides secure access to the printer. A Lock lock is available as an option on the CD800 single- hopper printer. About the Printer...
  • Page 19: Printer Right Side

    Printer Supplies Access The door provides access to the printhead and Door ribbon on the optional multi-hopper printer. Reject Card Tray Unfinished cards or cards not processed properly are placed in the reject card tray. CD800 Card Printer User’s Guide...
  • Page 20: Printer With Single Input Hopper

    Printer with Single Input Hopper                                                              Cover Latch Button Cover Ridges Card Input Hopper Ribbon Cartridge Handle Output Front Panel Hopper                                                                                                                           Cover Open the cover to access the printhead and ribbon. Latch Button Push the latch button to release the cover and open the printer.
  • Page 21: Printer With Optional Multi-Hopper

    Use the cartridge handle to remove it from the printer. Multi-Hopper Cover Unlock the printer and open the multi-hopper cover to load card stock. Card Hoppers H1 The H1 through H6 hoppers hold up to 100 cards through H6 each. CD800 Card Printer User’s Guide...
  • Page 22: Print Ribbon Cartridge

    Print Ribbon Cartridge                                                                                                                           Print Ribbon Cartridge Ribbon Cartridge Print Ribbon Handle Replaceable Cleaning Sleeve Print Ribbon Cartridge The cartridge holds the ribbon for printing. Print Ribbon The ribbon applies images to cards. Replaceable Cleaning The cleaning sleeve removes dust and other particles Sleeve from cards to maintain print quality.
  • Page 23: Printer With Optional Clm Laminator

    Laminator Laminator Access Door Laminator The optional laminator attaches to the printer and applies patch or topcoat overlay material to the card. Laminator Access Door Open the door to access the laminator cartridges. Refer to Appendix A, "CLM Laminator" on page A‐1 for complete information  about using a laminating system. CD800 Card Printer User’s Guide...
  • Page 24: System Label

    System Label The printer configuration label on  Configuration Label the side of the cover swingarm  shows the components installed. It  provides information that is useful  when requesting service.  The label shows the following  information: Printer name • Configuration, which includes options installed in the printer • Date and country of assembly • MAC address to use when the printer is connected via an Ethernet network • Information for components installed by the dealer or sales group is handwritten  on the label. About the Printer...
  • Page 25 CD800 Card Printer User’s Guide...
  • Page 26 About the Printer...
  • Page 27: Chapter 3: Using The System

    Chapter 3: Using the System This section provides information about how a card travels through  the printer, printer controls, printing a test card, loading and  replacing supplies, and cleaning the printer. How the Card Travels The card is verified and sent to print from the PC. The hopper pick mechanism  picks a card and moves the card into the printer for processing. Optionally, the card moves to the magnetic stripe encoding area or to the smart  card park station, depending on the type of card selected. Encrypted data is  decrypted and written to the card. If the printer includes a laminator, the card  then moves into the laminator where the overlay material is applied to the front  and back of the card. The finished card exits the printer through the card output  hopper. CD800 Card Printer User’s Guide...
  • Page 28: Card Printer System Overview

    Card Printer System Overview The card printer is used with other equipment and software to create a card  production system. The system produces cards for a specific purpose, and the  cards must meet requirements.  Equipment The system can include: A PC, with software to support the printer, such as:  The XPS Card Printer Driver for Windows.  • ID software designed specifically to capture, format, and save the data for  • cards.  ® ® A retail application such as Microsoft  Word or Adobe® Photoshop .  • Capture devices, such as:  A digital camera connected to the PC to take photos for ID badges and  • other cards.  A signature capture pad or fingerprint reader.  • The printer with supplies and a facility power source.  A data connection between the printer and PC, which can be a USB  connection or a network connection. (Do not use both with one printer.)  Tasks and Users Typical roles in a card production system include: The operator, who makes cards, loads supplies, and handles minor problems  • such as card jams.  The system administrator, who sets up the card printer and other hardware,  • sets up card designs, configures card production software, and identifies the  best use of the card printer in the organization. ...
  • Page 29: Printer Controls

    Printer Controls The front panel of the printer provides the controls for operating the printer. The  front panel controls are described in the following sections.                                                              LCD Panel Status Lights Ribbon Cards Power Button User Light & Down Enter User Button Arrow Arrow Power Button Use the P  button to power off and power on the printer. All lights show  OWER steady amber while the printer powers on. To power off the printer, press the button for 1 to 2 seconds until the printer  begins to shut down.  To power off the printer while it is processing cards, press the button for  2 seconds or more. Card jobs in the printer are not completed. CD800 Card Printer User’s Guide...
  • Page 30: Lcd Panel Menus

    LCD Panel Menus The LCD panel shows the printer’s  menus and displays printer  messages or conditions. Refer to  “Respond to Messages” on page  67 for more information.  The menu system has four major  branches:  Maintenance Use the  menu to  • run a cleaning card or print a  test card.  Status Use the  menu to see  • settings and data about the  printer.  Configuration Use the   menu to  • change settings.  Use the Activate menu to  • enable or disable secure  features of the printer.  Use the Activate menu only during installation or removal of systems that  require activation.  & T INTS Ready You can access the menu system when   displays on line 1 of the LCD  • panel.  Ready The printer returns to the ...
  • Page 31: User Button And Light

    The system is not ready or a Amber, Green, door on the system is open. Light Green, Off The colors cycle quickly. Close and Lock Doors displays on the LCD panel if no other message is present. CD800 Card Printer User’s Guide...
  • Page 32: Down Arrow, Up Arrow, And Enter Key

    Down Arrow, Up Arrow, and Enter Key Use the arrow keys to move through the printer menu system, and the E  key  NTER to make a selection.  Ready Press the up or down arrow key while the LCD panel displays   to display  additional information about the printer on line 2, including the firmware version,  printer model, serial number, and network IP address or USB IP address. If your  system includes a laminator, the laminator firmware version and laminator serial  number also display. If you don’t press a key for 30 seconds, the LCD panel  Ready returns to the default   message.  Ribbon Light The ribbon indicates the status of the print ribbon in the printer. Indicators  include the following:                                                               Off The print ribbon is okay.                                                              Blinking amber A blinking light indicates one of the following: The printer problem applies •...
  • Page 33: Retrieve The Printer Ip Address

    NTER Status Press the down arrow to display   on line 2. Press E  to enter the Status menu. NTER Network Status Press the down arrow key until    displays on line 2. Press E  to display the Network Status menu.  NTER IP Address Press the down arrow key until   displays on  line 2. Press E  to display the IP address. Record the IP  NTER address. Press E  to return to the Network Status menu.  NTER Subnet Mask  displays on line 2. Press E  to display the subnet mask. Record it, if  NTER necessary. CD800 Card Printer User’s Guide...
  • Page 34: Print A Test Card

    Press E  to return to the Network Status menu.  NTER Gateway Address  displays on line 2. Press E  to display the gateway address. Record it,  NTER if necessary. Press E  to return to the Network menu. NTER Exit Press the down arrow key to scroll to   on line 2. Ready Press E . Then, press the U  button to return the printer to  . The  NTER  button glows green.    Print a Test Card The printer includes a test card that runs without using a driver or other source of  card data. Use it to verify that the printer is working. Ready Begin with the printer  . The U  button shows  steady green. Suspended Press the U  button to display   on line 1  of the LCD panel. Press E  to enter the menu system.
  • Page 35: Load And Replace Supplies

    Load and Replace Supplies To prepare the printer to print cards, load blank card stock into the input hopper,  and load print ribbon and a cleaning sleeve onto the print cartridge. If your system includes the optional laminator, also load overlay material  into the L1 and L2 (if equipped) laminators. Refer to "Load Laminator  Overlay Material" on page A‐9, for information about loading the  laminator cartridges. Load Cards Do the following to load cards in the printer. Single Hopper Unlock the printer, if necessary,  and open the input hopper. Load the cards into the input  hopper. (Cards can stick together.  Slide or fan the cards to separate  the edges before placing them in  the input hopper.)  Insert ISO magnetic stripe  • cards with the stripe (back  side) facing down and toward the right. Insert smart cards with the smart card chip facing up and toward the back  • of the hopper. Close the input hopper and lock the printer, if necessary. CD800 Card Printer User’s Guide...
  • Page 36: Optional Multi-Hopper

    Optional Multi-Hopper Unlock the printer and open the multi‐hopper. Load the cards into the hoppers. The input hoppers are labeled H1  through H6. You can load up to 100  cards into each hopper. (Cards can  stick together. Slide or fan the  cards to separate the edges before  placing them in the input hoppers.) Insert ISO magnetic stripe cards  • with the stripe (back side)  facing down and toward the  right side.  Insert smart cards with the smart card chip facing up and toward the back  • of the hopper. Close the multi‐hopper and lock the printer when you finish loading cards. Load the Print Ribbon Load the print ribbon when you install the printer and when the ribbon runs out. Unlock the printer, if necessary, and open the printer supplies access door on  the optional multi‐hopper. Open the printer cover.                                                                                                                           Remove the print ribbon cartridge.  Using the System...
  • Page 37: Load The Cleaning Sleeve

    Load a full roll of print ribbon (the blue  spool) onto the spindle closest to the  cartridge handle.  Place the silver take‐up spool on the  spindle with the black gear.  Wind the take‐up spool counterclockwise  one full turn. Load the Cleaning Sleeve Load a new cleaning sleeve when you  load a new roll of print ribbon, when you  notice debris on the printed cards, or  when the cleaning sleeve is no longer  sticky. The printer ships with the cleaning roller  spindle installed on the print ribbon  cartridge. Remove the cleaning roller spindle  from the ribbon cartridge and slide  the spindle into the continuous cleaning sleeve (a).  Place the spindle with the cleaning sleeve onto the ribbon cartridge (b).  Remove the protective wrapper from the cleaning sleeve (c).  CD800 Card Printer User’s Guide...
  • Page 38: Install The Ribbon Cartridge

    Install the Ribbon Cartridge Install the assembled print ribbon cartridge into the printer. Open the printer cover. Hold the print ribbon cartridge by the handle and lower it into the printer  with the handle toward the front of the printer. Make sure that the ribbon cartridge is positioned correctly in the guides.  Close the printer cover. Press down on the ridges on the  front of the cover to make sure that it latches properly on  both sides.  Close the supplies access door on the optional multi‐ hopper. Lock the printer, if necessary. Using the System...
  • Page 39: Chapter 4: Printing Cards

    Chapter 4: Printing Cards Before Starting to Print This section explains how to print a card. Make sure that: Cards are loaded in the printer or available to insert. • Ribbon is loaded in the printer. For the steps to follow, refer to “Load the  • Print Ribbon” on page 22. If your system includes the optional laminator,  refer to Appendix A, "CLM Laminator" on page A‐1, for information about  preparing the laminator. The card design is set up. If you need to set up or modify the design, refer to  • “Elements of Card Design” in your printer’s Installation and Administrator’s  Guide.  & T INTS Make sure that magnetic stripe cards are loaded correctly. The printer shows the  correct position. You also can: Print a test card directly from the printer. Refer to “Print a Test Card” on  • page 20. Print a driver sample card. Refer to “Print a Driver Sample Card” in your  • printer’s Driver Guide.                                                     CD800 Card Printer User’s Guide...
  • Page 40: Print Cards

    Print Cards Make sure that cards are loaded in the printer or available to insert when  prompted. For the steps to follow, refer to “Load Cards” on page 21. Print from ID Software From the ID software, use the template or design for the card. Select the printer if you use more than one printer. Enter the data for the card. Follow the instructions for your software. Capture the photo for the card, if necessary. Click the Print button to send the card to the printer. At the printer, insert a card in the single‐feed slot, if necessary. Print from Other Software Open the software application and select the  card printer as the current printer. Use the applications setup page to select the  ISO ID‐1 page size, or set the page size to  2.13 x 3.38 in.  Set the margins to 0 (zero). Select an orientation—portrait or landscape. Create the card design: Add graphics, such as a company logo or background. Add a photo. Add text information, such as name,  address, or employee number. For information about additional card  features, refer to “Elements of Card Design” in  your printer’s Installation and Administrator’s  Guide. Printing Cards...
  • Page 41 Click Print to send the card to the printer. At the printer, insert a card into the printer, if necessary.  & T INTS The printer can receive card jobs from more than one PC. It prints cards in the  • order they are received. Orient all cards the same way. • Do not touch the card surface to be printed. Handle cards by their edges or  • wear gloves. CD800 Card Printer User’s Guide...
  • Page 42 Printing Cards...
  • Page 43: Chapter 5: System Maintenance

    Chapter 5: System Maintenance Clean the Printer The printer performs best when it is cleaned on a regular basis. Follow the  cleaning guidelines for your site to keep the printer in good working condition.  Clean the printer when: The printer displays a message for which cleaning is a solution. • There is debris on completed cards. • A new roll of print ribbon is installed. • You can perform the following cleaning tasks: Clean the Printhead on page 30 • Run a Cleaning Card on page 32 • Clean the Laminator on page A‐13 • CD800 Card Printer User’s Guide...
  • Page 44: Clean The Printhead

    Clean the Printhead Clean the printhead when: The printhead is replaced. • There are unprinted lines on the finished card. This usually indicates dirt or  • contaminants on the printhead.  The printhead is touched accidentally. Oils from hands can affect print quality  • and damage the printhead.  Do the following to clean the printhead: Power off the printer. Unlock the printer, if necessary, and open the printer supplies access door on  the optional multi‐hopper.  Open the printer cover and remove the print ribbon cartridge.                                                              Open and remove a cleaning swab from its package. System Maintenance...
  • Page 45 Use gentle pressure to move the cleaning swab back and forth along the full  length of the printhead edge until it is completely clean. Replace the print ribbon cartridge. Avoid bumping the printhead when you  install the print ribbon cartridge.                                                              Close the printer cover. Press down on the ridges on the front of the cover to  make sure that it latches properly on both sides. Close the supplies access  door on the optional multi‐hopper and lock the printer, if necessary. Power on the printer. Print a sample card to verify the quality of printing. Refer to “Print a Test  Card” on page 20 for more information.  & T INTS Avoid touching the printhead edge with your fingers. Contamination due to  • skin oils eventually can damage the printhead. Avoid touching the printing edge of the printhead cartridge with any sharp  • objects that can permanently damage the printhead. Use only the cleaning swab to clean the printhead. Other materials can stick  • to the printhead and cause damage. Use a cleaning swab one time only. Discard it after you clean the printhead. • CD800 Card Printer User’s Guide...
  • Page 46: Run A Cleaning Card

    Run a Cleaning Card Run a cleaning card to clean debris from the inside of the printer and from the  hopper rollers. The cleaning card can remove most contaminants from the  printer. Run a cleaning card after every 250 cards processed by the printer, or  every 6 months. Single Hopper Prepare the printer for cleaning. Power on the printer. Unlock the printer, if necessary. Open the printer cover and remove the  print ribbon cartridge. Close the cover. Open the input hopper and remove any  unprinted cards. Open the cleaning card package and  remove the cleaning card. Load the cleaning card in the input  hopper. (Plan to clean the printer  immediately. The cleaning card dries  out if it is out of its package for more  than a few minutes.)  Close the input hopper and lock the  printer, if necessary. System Maintenance...
  • Page 47  button.  Suspended  displays on line 1 of the LCD panel. Press the E  key to enter the menu system.  NTER Maintenance  displays on line 2 of the LCD panel. Press the E  key to  NTER Maintenance enter the   menu. Cleaning Card  displays on line 2 of the LCD panel. Press the E  key to  NTER Cleaning Card enter the   menu. Start  displays on line 2 of the LCD panel. Press the E  key to start the  NTER cleaning process. Insert cleaning card  displays on the LCD panel. Press the U  button to  start the cleaning cycle. CD800 Card Printer User’s Guide...
  • Page 48 The printer moves the card through the printer several times and ejects it  into the output hopper.  If you are cleaning a system with a laminator, the cleaning card moves into  the laminator after cleaning the printer and cleans the laminator rollers and  card entry area. The cleaning card is ejected into the laminator output  hopper. Remove the used cleaning card. Wait a few minutes for the rollers to dry. Prepare the printer for use. Unlock the printer, if necessary. Replace the cards in the input hopper. Install a new cleaning sleeve on the ribbon cartridge and remove the  protective cover. Refer to “Load the Cleaning Sleeve” on page 23 for the  steps to follow. Replace the ribbon cartridge and close the printer cover. Press down on  the ridges on the front of the cover to latch it properly. Ready Press the User button to return the printer to  . The printer is  available to print cards again. Discard the used cleaning card and cleaning sleeve.  & T INTS Use the cleaning card and cleaning sleeve one time only. • Change the cleaning sleeve each time you clean the printer or change the  • print ribbon. If the card light is blinking amber and there are cards in the input hopper, the  printer’s configured cleaning count has been reached and it is time to clean the  printer. The cleaning count is set in Printer Manager. Refer to the printer’s  Installation and Administrator’s Guide for complete information about using  Printer Manager. System Maintenance...
  • Page 49: Optional Multi-Hopper

    Optional Multi-Hopper Cleaning a printer equipped with the optional multi‐hopper involves two steps:  cleaning the printer and cleaning the hopper rollers. To start the cleaning process,  refer to Prepare the Printer for Cleaning. Prepare the Printer for Cleaning Power on the printer. Unlock the printer and open the printer  supplies access door. Open the printer cover and remove the  print ribbon cartridge. Remove the cleaning sleeve from the  ribbon cartridge. (The ribbon must  remain installed on the ribbon cartridge.) Replace the ribbon cartridge in the  printer and close the cover. Open the multi‐hopper door and remove  any unprinted cards. Open the cleaning card package,  remove the cards, and insert the  cleaning cards into the hoppers. (Plan  to run the cleaning cards immediately.  The cleaning cards dry out if they are  out of the package for more than a  few minutes.) Close the multi‐hopper door and lock  the printer. The front panel displays  Ready  and the U  light shows steady  green. Continue with “Clean the Printer” on page 36. CD800 Card Printer User’s Guide...
  • Page 50: Clean The Printer

    Clean the Printer Make sure that you have prepared the printer for cleaning. Refer to “Prepare  the Printer for Cleaning” on page 35. Press the U button. SER  Suspended displays on line 1 of the LCD panel.  Press the E  key. NTER                                                              Maintenance  displays on line 2 of the LCD panel. Press the E  key to enter  NTER Maintenance the   menu.                                                              Cleaning Card  displays on line 2 of the LCD panel. Press the E  key to enter  NTER Cleaning Card the  menu.                                                              Printer  displays on line 2 of the LCD panel. Press the E  key. NTER                                                              System Maintenance...
  • Page 51: Clean The Hopper Rollers

                                                                 Insert cleaning card  displays on the LCD panel. Press the U  button to start  the cleaning cycle.                                                              The printer picks the cleaning card from hopper 2 (H2) and moves it through  the printer several times. The used cleaning card is placed in the reject card  tray. Ready The printer returns to   when the cleaning cycle completes. Continue with Clean the Hopper Rollers. Clean the Hopper Rollers Cleaning Card Access the LCD menu system and enter the   menu.                                                              Select the hoppers for cleaning. Hopper Press the down arrow key until  displays on line 2 of the LCD panel. Hopper Press the E key to enter the  menu. NTER                                                               CD800 Card Printer User’s Guide...
  • Page 52: Prepare The Printer For Use

    Press the down arrow key and choose  to clean hoppers H1, H3, H4, H5,  1 through 6 and H6. (Or, continue pressing down to select hoppers  to clean  a hopper individually.)                                                              Press the E key to start the cleaning process. NTER  The printer moves the cleaning cards back and forth across the hopper rollers  several times and then ejects the cleaning cards back into the hoppers. Ready The printer returns to   when the cleaning cycle completes. To complete the cleaning process, refer to Prepare the Printer for Use. Prepare the Printer for Use Unlock the printer and open the multi‐hopper door.  Remove the used cleaning cards from the hoppers. Replace the unprinted cards in the input hoppers. Open the printer supplies access door and  the printer cover. Remove the print ribbon  cartridge. Install a new cleaning sleeve on the ribbon  cartridge and remove the protective cover.  Refer to “Load the Cleaning Sleeve” on  page 23 for the steps to follow. Replace the ribbon cartridge. Close the printer cover. Press down on the  ridges on the front of the cover to latch it properly. Close the printer supplies access door.  Open the reject card tray and remove the used cleaning card. System Maintenance...
  • Page 53 Lock the printer. Ready The printer returns to   and is available to print cards again.                                                              Discard the used cleaning cards and cleaning sleeve.  & T INTS Use the cleaning cards one time only. • Change the cleaning sleeve each time you clean the printer or change the  • print ribbon. CD800 Card Printer User’s Guide...
  • Page 54 System Maintenance...
  • Page 55: Chapter 6: Troubleshooting

    Chapter 6: Troubleshooting This section helps you identify and fix basic issues that can occur during printing.  Also refer to your printer’s Driver Guide or OpenCard manual for additional  troubleshooting information. The section starts with an overview of card production and printer issues you may  encounter: Locate a Problem Within the Card Production System on page 42 • Locate a Problem with Basic Printer Functions on page 43 • This section also describes troubleshooting for the following: Installation Problems on page 44 • Card Printer Driver Problems on page 46 • Card Appearance on page 48 • Magnetic Stripe Problems on page 54 • Laminator Problems on page 56 • Card Jams on page 61 • Messages and Conditions on page 62 • CD800 Card Printer User’s Guide...
  • Page 56: Locate A Problem Within The Card Production System

    Locate a Problem Within the Card Production System For typical components of the system, refer to “Card Printer System Overview”  on page 14. If any one of the following components does not work properly,  printing cards can be affected. The XPS Card Printer Driver • Should you need to reinstall the Card Printer Driver to fix a problem, we  recommend you download the latest version of the driver from http:// www.datacard.com. Select Support > Drivers & Downloads from the menu.  Enter your printer model in the Enter Product Name or Number area, and  click Go. Card production software • Card production software formats the types of data used to print cards. Make  sure that the card production software features you use work with your  printer. If you do not use card production software, make sure that the software you  use supports the requirements for creating cards. If you use magnetic stripe  data, use an application that saves text as text and not as a graphic. (For  example, Microsoft Paint only saves graphic data, while Adobe Photoshop  saves both graphic and text data.) Fonts and escapes require that text is sent  from the application as text. Printer plug‐in • Card production software might require a printer plug‐in, which makes the  data in the card production software available in the form the Card Printer  Driver can use. Other components of the system • An ID or badge system usually includes a camera to take photos, and may  include other capture devices for biometric data. The proper use and  maintenance of these components is important to the quality of cards you  produce.
  • Page 57: Locate A Problem With Basic Printer Functions

    Make sure that the power cord is plugged in and the printer is powered on.  Ready Does the printer power on and display   on the front panel within  1 minute? If the printer powers on correctly, continue to step 3. • Ready If the printer powers on but does not display  , the printer is not  • working properly. Request service for the printer. If the printer does not power on, make sure that the power source is  • functioning by doing one of the following: Remove the printer power cord from the outlet and connect it to  • another outlet. Remove the power cord from the printer and connect it to another  • device, such as a light, and then connect it to the same outlet. If the power source is functioning, there is a problem with the printer.  Request service for the printer. If the power source isn’t functioning, replace it and then begin with  step 1. Print a test card. Refer to “Print a Test Card” on page 20 for more  information.  If the test card prints, the printer is working correctly. Continue to step 4. • If the test card does not print, the printer is not working correctly. Request  • service for the printer. Connect the printer data cable, if necessary. Make sure that you use the same  type of cable (USB or network) used when the printer was installed. CD800 Card Printer User’s Guide...
  • Page 58: Installation Problems

    If you use the XPS Card Printer Driver, print a driver sample card. For the steps  to follow, refer to your printer’s Driver Guide. If the sample card prints, the printer and driver are working correctly.  • Continue to step 6. If the sample card does not print, the printer and driver have a  • communication problem. Determine the cause of the problem and try the  sample card again. If you are not using the Card Printer Driver, ask your service provider or  software provider for assistance. Print a card using your card production software. If the card prints, your software is working successfully with the printer.  • Troubleshoot the card design. If the card does not print, check the following: • In the application, is the correct printer selected in the Print Setup or  • Print dialog? If the printer produced a blank card, review the page size or driver  • settings. If the card causes an error, the card might have a type of data the printer does not  support. Installation Problems This section describes issues that prevent a successful installation and provides  recommended solutions to those issues. Choose from the following topics:  USB Installation Troubleshooting on page 45 • Network Installation Troubleshooting on page 46 • Troubleshooting...
  • Page 59: Usb Installation Troubleshooting

    Hibernation on a laptop PC requires several moments to enable USB communication. Unplug the USB printer port and then connect it again. Replace the PC port or the PC. Contact your PC or port vendor if you need assistance. CD800 Card Printer User’s Guide...
  • Page 60: Network Installation Troubleshooting

    Network Installation Troubleshooting Problem Solution The network cable is Reconnect the data cable to the network port and loose. the printer. Restart the printer. The Status page of Follow your network troubleshooting procedures to Printer Properties shows isolate and test each component of the computer- the printer is not to-printer communication link.
  • Page 61: The Card Printer Driver Does Not Detect The Network-Connected Printer

    You cannot switch the type of Message 500 displays data cable after installation. after you send a card Make sure that both ends of the data cable are to print. connected. Replace a defective USB cable if needed. CD800 Card Printer User’s Guide...
  • Page 62: Driver Status Or Windows Print Queue Does Not Provide Expected Data

    Driver status or Windows print queue does not provide expected data Problem Solution The Card Printer Driver Check the following: sample card or Enable bidirectional support must be selected • magnetic stripe test on Printer Properties > Ports tab to allow printing cards do not print.
  • Page 63: Something Did Not Print

    100% black background to a color near black, so that it prints using the YMC (color) panels of the print ribbon. Refer to “Elements of Card Design” in the printer’s Installation and Administrator’s Guide for more information about color printing. CD800 Card Printer User’s Guide...
  • Page 64: Printing Includes Unexpected Data

    Printing includes unexpected data Problem Probable Cause Solution Text that was intended The magnetic stripe Refer to “Magnetic Stripe Fonts” in the for the magnetic stripe font was not applied to printer’s Driver Guide. printed on the card the text. instead.
  • Page 65 Run a cleaning card. Refer to “Run a the card packaging Cleaning Card” page 32. Use cards contains debris. that meet the requirements for the printer. Refer to “Cards” in your printer’s Installation and Administrator’s Guide. CD800 Card Printer User’s Guide...
  • Page 66: The Printing Is Too Light

    The printing is too light Problem Probable Cause Solution Photos look faded. The image capture Color settings might not be optimal. system needs Adjust color settings. Refer to the adjustment. documentation for the image capture system, “Color Printing” in your printer’s Installation and Administrator’s Guide, and “Color Adjustment Tab”...
  • Page 67: The Monochrome Printing Has Flaws

    Microsoft Word, to create the color panels. and Fax Viewer is card. printing the file. Many applications use the Windows tool to preview and print graphics. The tool does not render to true black and white. CD800 Card Printer User’s Guide...
  • Page 68: Magnetic Stripe Problems

    Magnetic Stripe Problems To begin troubleshooting a magnetic stripe problem, first print a magnetic stripe  test card from Printer Manager or the Card Printer Driver. For the steps to follow,  refer to the “Printer Manager” section of the printer’s Installation and  Administrator’s Guide or “Printing a Driver Sample Card” in the card printer’s  Driver Guide. The printer uses the coercivity set using the LCD panel or in Printer Manager, and  the data format set using Printer Manager. Problem Solution Cards are not loaded Load ISO cards with the magnetic stripe (back side) correctly. facing down and toward the right. Refer to “Load Cards” page Cards do not have a Load magnetic stripe cards in the input hopper.
  • Page 69 If the printer label indicates a single-track JIS module, you can send data for track 1. The magnetic stripe option and cards must be capable of accepting and encoding each track of data sent by the card production software. CD800 Card Printer User’s Guide...
  • Page 70: Laminator Problems

    Laminator Problems This section describes problems that might occur when you are using a laminator  to apply overlay to the card. Patch Appearance Problems Problem Probable Cause Solution Smart cards don’t work The Debow card Make sure that the Debow card option in after the overlay is option is selected. the Card Printer Driver is not selected. applied.
  • Page 71 Use the correct patch material for your such as a smart card card type. Refer to "Laminator Overlay chip, that interfere with Materials" page A-6 for a description application of the of overlay types. overlay. CD800 Card Printer User’s Guide...
  • Page 72: Topcoat Appearance Problems

    Problem Probable Cause Solution The patch shows The temperature for Decrease the laminator temperature opaque areas at the applying the overlay is setting. Refer to the Printer Manager leading edge of the too high. “Laminate Type” section of the printer’s card.
  • Page 73 If it doesn’t, remove leading edge of the direction on the take- the cartridge and turn the take-up spool card. up spool. clockwise several turns. CD800 Card Printer User’s Guide...
  • Page 74: Use Advanced Troubleshooting Tools

    Problem Probable Cause Solution The hologram of the The Card Printer Driver Change the Laminate card setting to topcoat doesn’t Laminate card setting apply the overlay. Refer to the printer’s appear on the card. is set to Do not apply. Driver Guide for information about specifying lamination settings.
  • Page 75: Card Jams

    Card Jams The card did not reach the position for the next action, such as printing or ejecting  the card. You usually can resolve the error by pressing the U  button so that the printer  Ready displays  . If the error persists, do the following to remove the card from the  printer. Unlock the printer, if necessary, and  open the printer cover. Remove the print ribbon cartridge.Turn  the manual advance knob to move the  jammed card until it is accessible from  the rollers. Remove the card. Replace the ribbon cartridge and close  the printer cover. Lock the printer, if  necessary. Press the U  button on the printer or click Retry in the message box.  & T INTS Check the ribbon to make sure that it is not torn. Refer to “109: Print ribbon  problem” on page 70 to repair or replace the ribbon, if needed. For laminator card jams, refer to "Clear Laminator Card Jam" on page A‐12. CD800 Card Printer User’s Guide...
  • Page 76: Messages And Conditions

    Messages and Conditions When the printer cannot process the card sent, it issues a condition. The LCD  panel on the front panel shows these conditions. If you use the XPS Card Printer  Driver, the printer driver also displays the condition as a message on the PC. In a  shared printer environment, messages can differ slightly from the messages and  conditions described in this section. Messages on the Printer LCD • Messages from the XPS Card Printer Driver on the PC on page 66 • Messages from Printer Manager on page 66 • Other Messages on page 66 • Messages on the Printer LCD All messages are associated with a print job. The printer issues messages that  focus on recovering from problems.  The printer displays a message number and a short description for each  • message.  If more than one message was issued, the next message displays after you  • correct the problem and press the U  button. The lights on the front panel flash while messages display on the LCD panel. • LCD Message User Light Supply Light Card Light Sound –...
  • Page 77 Amber Flash Off Warning Insert new card side 1 up Amber Flash Off Warning Insert same card side 1 up Amber Flash Off Warning Insert cleaning card Amber Flash Off Warning Improper shutdown Amber Flash Off Warning CD800 Card Printer User’s Guide...
  • Page 78 Supply Laminator LCD Message User Light Light Card Light Light Sound Laminator not available Green Error Flash Laminator error critical Green Amber Green Red Flash Error Flash Flash Flash Laminator entry card Green Red Flash Error problem Flash L1 area card problem Green Red Flash Error...
  • Page 79 Error Flash Impresser heater problem Green Red Flash Error Flash Bar code scanner Green Red Flash Error problem Flash Firmware version Green Red Flash Error mismatch Flash Laminator system Green Red Flash Error mismatch Flash CD800 Card Printer User’s Guide...
  • Page 80: Messages From The Xps Card Printer Driver On The Pc

    Messages from the XPS Card Printer Driver on the PC The Card Printer Driver displays the same messages as those on the printer  • LCD panel. The messages that display on the PC provide additional  information about the condition that caused the message and contain  recovery instructions. Click the appropriate button in the message box to  clear the message. Messages display on the PC that sent the card print job.  • If you cancel a job at the printer, the message is removed from the PC. Any  • additional messages for the canceled job (for example, for a broken ribbon)  do not display on the PC.  Messages can display in the background, behind the application sending the  • card. On some operating systems, the message displays in the status bar. Click  the blinking Explorer (folder) icon in the status bar to open the message.  If more than one message was issued, the next message displays after you  • close the current message.  If there is more than one card printer installed on the PC, messages display  • one at a time. The title bar of each message shows the printer name.  If there is more than one card printer installed on the PC and each has issued  • errors, the printer driver displays the messages received, even if you cleared  the error at the printer.  The Card Printer Driver can issue messages that do not display on the printer  • LCD panel. Refer to “Driver‐Only Messages” on page 82 and “Driver SDK  Messages” on page 84 for a list of these messages. Messages from Printer Manager Printer Manager issues messages that display in a web browser window. Click ...
  • Page 81: Respond To Messages

    The following messages display on the printer LCD panel and in a message box on  the PC that issued the card print job when you use the Card Printer Driver. 100: Request not supported The printer does not support the personalization being requested for the card.  The card will be canceled. Change the card data to match the printer’s options and settings, or print to a  printer that is configured to support the personalization being requested. Press the U  button on the printer, or click OK in the message box to clear the  message. 101: Job could not complete The card took too much time to complete. The card will be canceled. Press the U  button on the printer, or click OK in the message box to clear the  message. 102: Card not in position The card is not positioned in the printer correctly.  Open the printer and remove the ribbon cartridge. Turn the knob to remove the card. Replace the ribbon cartridge and close the printer. Press the U  button on the printer. In the message box, click Retry, or click  Cancel to cancel the card. CD800 Card Printer User’s Guide...
  • Page 82: 103: Printer Problem

    103: Printer problem The printer had an error. The card will be canceled.  Press the printer P  button to power off the printer.  OWER Press the P  button again to power on the printer. OWER Click OK in the message box to clear the message. 104: Critical problem The printer had a serious error. The card will be canceled. Press the printer P  button to power off the printer. OWER Request service.  The system must remain powered off. Click OK in the message box to clear the message. 105: Magstripe data error The printer failed to verify that the correct magnetic stripe data was written on  the card.  Make sure that you are using magnetic stripe cards that match the printer  settings. Make sure that the cards are placed in the printer correctly. Press the U  button on the printer. In the message box, click Retry, or click  Cancel to cancel the card.  & T INTS The card might have been turned the wrong way. • The card might not have a magnetic stripe. • Troubleshooting...
  • Page 83: 106: Magstripe Data Not Found

    106: Magstripe data not found The printer did not find magnetic stripe data on card. Make sure that you are using magnetic stripe cards that match the printer  settings. Make sure that the cards are placed in the printer correctly. Press the U  button on the printer. In the message box, click Retry, or click  Cancel to cancel the card.  & T INTS The card might not match printer settings or the data sent. • Ask the system administrator to verify that the card, the data, and the printer  • settings match. 107: Magstripe read data error The printer failed to read the magnetic stripe data from the card. The card will  be canceled. Make sure that you are using magnetic stripe cards that match the printer  settings. Make sure that the cards are placed in the printer correctly. Press the U  button on the printer, or click OK in the message box to clear the  message.  & T INTS The data might use a different format than the current printer setting. • Ask the system administrator to verify that the card, data, and printer settings  • match. CD800 Card Printer User’s Guide...
  • Page 84: 108: Magstripe Read No Data

    108: Magstripe read no data The printer did not find any magnetic stripe data on card. The card will be  canceled. Make sure that you are using magnetic stripe cards that match the printer  settings. Make sure that the cards are placed in the printer correctly. Press the U  button on the printer, or click OK in the message box to clear the  message.  & T INTS The card might have been turned the wrong way. • The card might not have a magnetic stripe.  • 109: Print ribbon problem The print ribbon is not moving properly.  Open the printer and remove the ribbon cartridge.  Reposition, repair, or replace the ribbon and advance the repaired area one  full turn. Replace the ribbon cartridge and close the printer. Press the U  button on the printer. In the message box, click Retry, or click  Cancel to cancel the card. 110: Print ribbon out or missing The printer does not have usable ribbon. To complete the current card: Open the printer and remove the ribbon cartridge. Install a new ribbon and cleaning roller. Replace the cartridge and close the printer.
  • Page 85: 111: Card Not Picked

    112: Card hopper empty The printer did not detect cards in the input hopper.  Add cards to the input hopper. Press the U  button on the printer. In the message box, click OK, or click Cancel  to cancel the card. 113: Close cover to continue The printer cover must be closed to print.  Push down on the cover to latch it. Press the U  button on the printer. In the message box, click OK, or click Cancel  to cancel the card.  & T INTS Make sure that the ribbon cartridge is installed properly with the cartridge handle  even with the edges of the printer. 114: Cover opened during job The printer cover was opened while printing.  Push down on the cover to latch it. Press the U  button on the printer. In the message box, click Retry, or click  Cancel to cancel the card.   & T INTS Make sure that the ribbon cartridge is installed properly with the handle even  with the edges of the printer. CD800 Card Printer User’s Guide...
  • Page 86: 116: Magstripe Not Available

    116: Magstripe not available The printer does not have a magnetic stripe option. The card will be canceled. Remove magnetic stripe data from the card or use a printer that has a magnetic  stripe option installed. Press the U  button on the printer, or click OK in the message box to clear the  message.   & T INTS To remove magnetic stripe data, you or your system administrator may need to: Clear a check box in the card production application. • Change the font from Mag Track x XPS Card Printer to a printable font such as  • Arial, Verdana, or Calibri. Refer to “Magnetic Stripe Fonts” in your printer’s  Driver Guide. 117: Reader not available The printer does not support the personalization being requested for the card.  The card will be canceled.   Change the card data to match the printer’s options and settings or print to a  printer that is configured to support the personalization being requested. Press the U  button on the printer, or click OK in the message box to clear the  message.  & T INTS To remove the reader request, you or your system administrator may need to  clear a check box in the card production application. Troubleshooting...
  • Page 87: 118: Print Ribbon Type Problem

    119: Print ribbon not supported The printer cannot use the ribbon installed. The card will be canceled. Use ribbon designed for this printer. Press the U  button on the printer, or click OK in the message box to clear the  message.  & T INTS Purchase ribbon from your dealer or authorized reseller. • Check the Datacard website for newer firmware that supports new ribbon  • types. 120: User paused the printer The printer was paused while printing.  To complete the current card press the printer’s U  button. In the message box, click OK to clear the message and complete the current card,  or click Cancel to cancel the card.  & T INTS If the user pressed the U  button for several seconds, the card has been  • canceled. If this message occurs often, ask your system administrator to set the button  • sensitivity to a lower value. CD800 Card Printer User’s Guide...
  • Page 88: 121: Print Ribbon Not Identified

    121: Print ribbon not identified The printer cannot use the ribbon installed. The card will be canceled. Use ribbon designed for this printer. Press the U  button on the printer, or click OK in the message box to clear the  message.  & T INTS Ask your dealer or authorized reseller for a replacement ribbon. 122: Magstripe format problem The magnetic stripe data sent does not match the format set in the printer. The  card will be canceled. Press the U  button on the printer, or click OK in the message box to clear the  message. 123: Insert new card side 1 up Insert a new card in the printer with side 1 facing up. If the card is not immediately picked, press the printer’s U  button or  click OK. Click Cancel in the message box if you want to cancel the card. 124: Insert same card side 2 up Take the card from the printer.
  • Page 89: 149: Option Not Installed

     button on the printer, or click OK in the message box to clear the  message.  & T INTS In the card format, don’t include references to hardware that cannot be accessed  by the system. For more information, refer to your ID software documentation or  ask your system administrator. 150: Print while unlocked The printer is unlocked. The card will be canceled. Make sure that all access doors are closed securely and locked. Click OK in the message box to clear the message. 151: Failed to lock An attempt to lock the printer failed. The card will be canceled. Make sure that all access doors are closed securely. Try locking the printer again. Click OK in the message box to clear the message. 152: Insert new card side 2 up Turn a new card over end to end so side 2 is facing up. Insert the card in the printer. If the card is not immediately picked, press the printer’s U  button or  click OK. Click Cancel in the message box if you want to cancel the card. CD800 Card Printer User’s Guide...
  • Page 90: 153: Insert Same Card Side 2 Up

    153: Insert same card side 2 up Take the card from the printer and turn it over end to end so side 2 is facing  Insert the card in the printer. If the card is not immediately picked, press the printer’s U  button or  click OK. Click Cancel in the message box if you want to cancel the card. 170: Insert new card side 1 up Insert a new card in the printer with side 1 facing up. If the card is not immediately picked, press the printer’s U  button or  click OK. Click Cancel in the message box if you want to cancel the card. 171: Insert same card side 1 up Take the card from the printer and turn it over end to end so side 1 is facing  Insert the card in the printer. If the card is not immediately picked, press the printer’s U  button or  click OK. Click Cancel in the message box if you want to cancel the card. 172: Insert cleaning card Insert cleaning card.
  • Page 91: Laminator Messages

    177: Laminator not available The printer and laminator cannot communicate. The card will be canceled. Make sure the data cable from the laminator to the printer is securely plugged  Press the printer Power button to power off the system.  Press the Power button again to power on the system. 196: Laminator error critical The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 197: Laminator entry card problem The card is not where it should be in the laminator. Open the laminator. Turn the knob to remove the card.  Close the laminator. 198: L1 area card problem The card is not where it should be in the laminator. Open the laminator and remove the L1 supply cartridge. Turn the knob to remove the card.  Replace the supply cartridge and close the laminator. CD800 Card Printer User’s Guide...
  • Page 92: 199: L2 Area Card Problem

    199: L2 area card problem The card is not where it should be in the laminator. Open the laminator and remove the L2 supply cartridge. Turn the knob to remove the card.  Replace the supply cartridge and close the laminator. 200: Laminator exit card problem The card is not where it should be in the laminator. Open the laminator. Turn the knob to remove the card.  Close the laminator. 201: L1 supply problem The L1 supply is not moving properly. To try another card: Open the laminator and remove the L1 cartridge.  Reposition, repair, or replace the supply and advance the repaired area one  full turn. Replace the cartridge and close the laminator. 202: L1 supply out or missing The laminator does not have usable supplies.  Open the laminator. Replace the supply. Close the laminator. 203: L1 supply type problem The laminator cannot use the supply installed.
  • Page 93: 205: L1 Supply Not Identified

    207: L2 supply out or missing The laminator does not have usable supplies.  Open the laminator. Replace the supply. Close the laminator. 208: L2 supply type problem The laminator cannot use the supply installed. Use supplies designed for this laminator. 209: L2 supply not supported The laminator cannot use the supply installed. Use supplies designed for this laminator. 210: L2 supply not identified The laminator cannot use the supply installed. Use supplies designed for this laminator. 211: L1 heater problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. CD800 Card Printer User’s Guide...
  • Page 94: 212: L2 Heater Problem

    212: L2 heater problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 213: L1 heater sensor problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 214: L2 heater sensor problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 215: L1 heater roller problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 216: L2 heater roller problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 217: Debow problem The laminator has encountered an error in the debow area. ...
  • Page 95: 218: Impresser Problem

    219: Impresser sensor problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 220: Impresser heater problem The laminator has encountered a critical error. The card will be canceled. Press the printer Power button to power off the system.  Request service. The system must remain powered off. 221: Bar code scanner problem Open the laminator and remove the L1 cartridge. Verify the supply has bar codes printed on it. Replace the cartridge and close the laminator. Try the card again. If the problem occurs again, request service. 222: Firmware version mismatch The printer and laminator firmware versions are not compatible. The system  cannot laminate cards until the firmware has been updated. Update both the printer and laminator to the latest firmware versions.  223: Laminator system mismatch The printer and laminator are not compatible.  The laminator is not supported by your printer model. Contact your service  provider for the correct laminator model. CD800 Card Printer User’s Guide...
  • Page 96: Driver-Only Messages

    Driver-Only Messages The following messages are issued by the Card Printer Driver and display in a  message box on the PC that sent the card print job. These messages do not  display on the printer LCD panel. 500: The printer is not available The computer cannot communicate with the printer. To complete the current  card: Ready  Make sure that the printer is powered on and in the   state. Make sure the printer is connected to the computer using a USB or network  cable, but not both. When the printer is ready, click OK. Click Cancel if you want to cancel the card 501: The printer connection was lost The computer lost communications with the printer during printing. The card will  be canceled.  Make sure the printer is powered on. Make sure the printer connection to the computer is secure. Click OK to clear the message. 502: The card data is missing or is not usable The printer driver has detected invalid or missing data. The card will be canceled. ...
  • Page 97: 505: Usb Communication Issue

    The printer is busy processing an interactive job. The card will be canceled. Wait until the current card is complete and then try again. Click OK to clear the message. 507: The printer is unlocked The printer must be locked to print.  To complete the current card make sure that all access doors are closed securely  and locked. Click OK to clear the message, or click Cancel to cancel the card. 508: The printer is shutting down The printer is shutting down or resetting. The card will be canceled. When printer is powered back on, try again. Click OK to clear the message.  509: The printer is offline or suspended The printer must be online to print.  To complete the current card press the printer’s U  button until the printer  Ready returns to the   state. Click OK to clear the message, or click Cancel to cancel the card. CD800 Card Printer User’s Guide...
  • Page 98: 510: The Printer Is Unlocked

    510: The printer is unlocked The printer must be locked to resume printing. Make sure that all access doors are closed securely and locked. Click OK to clear the message, or click Cancel to cancel the card. Driver SDK Messages The following messages are issued when you use the Card Printer Driver Software  Development Kit (SDK) to define your card printing. The messages are returned  by the SDK to the application that sent the print job. These messages do not  display on the printer LCD panel or in a message box on the PC that sent the job. 511: Cannot lock or unlock the printer. Locks are not installed. Severity: Critical 512: Cannot lock or unlock the printer. The password is incorrect or invalid. Severity: Critical ...
  • Page 99: Appendix A: Clm Laminator

    Appendix A: CLM Laminator This appendix provides information about the optional CLM  laminator that you can add to your system at the time of purchase  or later, as a field upgrade. About the Laminator System A laminator system consists of a CD series card printer and a CLM laminator. The  system can print cards and apply an overlay material on the front and back of the  card for increased durability and security. Using an overlay material with  holographic or other transparent images also improves the security of the card.  These materials are tamper evident, making it difficult to reproduce or modify a  card. Your laminator may look different from the one shown in the illustrations, based  on the options installed. The information described in this appendix applies to all  CLM laminators.                                                              Printer Laminator                                                              CD800 Card Printer User’s Guide...
  • Page 100: Outside The Laminator

    Outside the Laminator Use the following information to become familiar with the laminator. Laminator Back and Left Side                                                              Printer Mounting Card Entry Pins Area Laminator Status Light Printer Mounting Pin Reject Card Tray Printer Mounting Lock Laminator Power Connection Printer Mounting Pins Align the printer with the laminator. Printer Mounting Lock Secures the printer to the laminator.
  • Page 101: Laminator Status Light

    The optional lock provides secure access to the Lock laminator. Note: If the laminator has a lock, the printer also must have a lock. Impresser The optional impresser is located inside the laminator just before the card exit slot. CD800 Card Printer User’s Guide...
  • Page 102: Inside The Laminator

    Inside the Laminator The CLM laminator has one standard laminator, in the L1 position, with an  optional second laminator in the L2 position. The laminators apply topcoat or  patch overlay material to the card. Topcoat is a continuous film and patch is a  die‐cut polyester shape. Both laminators can apply either overlay type. Refer to  "Laminator Overlay Materials" on page A‐6.                                                                                                                           Manual Advance Knobs Optional Bar Code Scanner L2 Laminator L2 Transport Laminator Access Door L1 Laminator Access Door Manual Advance The manual advance knobs move the card through the Knobs laminator to remove it from the system.
  • Page 103: Laminator Configuration Label

    If your system includes the optional second laminator (L2), make sure that the  laminator cartridge is always installed even if the cartridge is not loaded with  overlay material. If the cartridge is not in place, cards are not supported as they  travel through the system and can fall into the bottom of the laminator. Laminator Configuration Label The laminator configuration label is located inside the laminator beneath the L2  cartridge. Open the laminator access door and remove the L2 laminator cartridge  to see the label. If an L2 laminator is not installed, open the L2 transport access  door to see the label.                                                                                                                           CD800 Card Printer User’s Guide...
  • Page 104: Laminator Setup

    Laminator Setup The laminating system supports full‐color print ribbons that do not have a  topcoat (T) panel, including YMCK and YMCKK ribbon. The topcoat or patch  overlay applied by the laminators provides protection against wear and color  fading, so the print ribbon topcoat panel is not needed. However, the DuraShield  overlay requires that the ribbon topcoat be applied first. The system also supports full‐color print ribbon with a front‐side ultraviolet (UV)  fluorescing panel, YMCKF‐KT. The UV (F) panel is designed to create an optically  variable image on the card. Refer to the printer’s Driver Guide for information  about designing a card to use a UV ribbon. Laminator Overlay Materials The L1 and L2 laminators can apply either topcoat or patch material. Topcoat is a  continuous film and patch is a die‐cut polyester shape.                                                              Topcoat Patch Patch overlays have a registration mark that is used by the printer to align the  patch with the beginning of the card. The registration mark is a rectangular hole  between the patches. Patches can cover the entire card, can have an opening for a smart card chip, or  can cover the card under the magnetic stripe. If both L1 and L2 laminators are  installed, each laminator can apply different overlay material. For example, you  might apply a patch that covers the complete card on the front, and a patch sized  for a magnetic stripe on the back.                                                              Complete Smart Card Magnetic Stripe Card CLM Laminator...
  • Page 105 Both patch and topcoat overlays can be clear or can have a transparent  holographic image on them. The holographic materials are called holographic  topcoat or holographic patch and can be ordered with a custom image.                                                               Clear Patch Clear Topcoat Random Holographic Random Holographic Patch Topcoat In addition, both holographic topcoat and holographic patch can be designed with  a registered image that is located in the same position on each card. Registered  holographic topcoat has a registration mark so that the image can be aligned with  the card. Refer to the printer’s Installation and Administrator’s Guide for  information about ordering overlay material.                                                              Registered Holographic Patch Registered Holographic Topcoat If you use a custom holographic overlay, make sure that you know the location  of important card features, such as photos and logos. Do not place holographic  images where they interfere with the appearance of photos or machine‐ readable features. CD800 Card Printer User’s Guide...
  • Page 106: Serialized Overlay With Bar Code

    Serialized Overlay with Bar Code Serialized overlay is a special patch that is designed to provide an additional level  of security to your cards. The overlay includes a unique serialization code  matched with a bar code. The optional bar code scanner in the laminator  retrieves the unique value printed on each serialized overlay patch by reading the  matching bar code printed on the lamination material next to the patch. This  value is returned to your application, which can store the information in a file to  provide a traceable identifier that links the patch applied to the card with the  other data used to personalize the card.                                                              Registered Holographic Serialized Patch The bar code scanner is located inside the laminator in front of the L1 laminator  cartridge. The serialized overlay is always loaded in the L1 cartridge. You must use the XPS Windows Driver Software Development Kit (SDK) to  incorporate serialized overlay in your card production. Refer to the SDK  Programmer’s Reference Guide for complete information.  CLM Laminator...
  • Page 107: Load Laminator Overlay Material

    Load Laminator Overlay Material Load the overlay material in one laminator cartridge at a time.  The L1 (green) and L2 (orange) cartridges fit only in their assigned locations  inside the laminator. They are not interchangeable. Unlock and open the laminator  access door. Remove the L1 (green) laminator  cartridge from the printer. Place  the cartridge on a smooth level  surface for loading. Push the release latch (a) and  open the gate on the laminator  cartridge (b). Remove both used spools from the cartridge (if present). CD800 Card Printer User’s Guide...
  • Page 108 Load the new roll of laminator overlay  material.  Put the blue supply spool on the  blue supply spindle of the cartridge  (c). The overlay supply roll can go  on only one way and only fits on  the correct spindle. Put the empty silver take‐up spool  on the silver take‐up spindle (d).  Turn the take‐up spool clockwise to  remove slack from the material (e).  The overlay material loads in an  S‐shape. Make sure that the overlay material  is between the guides on both the  take‐up and supply sides of the  cartridge. Close the laminator cartridge gate (f).  Push it in until the latch clicks in  place (g). Make sure that the overlay  material is not pinched by the cartridge  gate. Replace the loaded laminator cartridge  in the printer.  Remove the L2 (orange) cartridge, if  installed, from the laminator. Repeat steps 3 through 7 to load the  overlay onto the L2 cartridge. Close and lock the laminator access door. A-10 CLM Laminator...
  • Page 109: Card Design

    If the printer has one laminator, you can apply the overlay material to one or  • both sides of the card.  If the printer has two laminators using different overlay materials, the  • quickest way to process a card is to apply the overlay in L1 to the front of the  card and the overlay in L2 to the back of the card. You can fine‐tune the settings that control the application of the overlay using  Printer Manager. Refer to the printer’s Installation and Administrator’s Guide for  information about using Printer Manager. Verify Setup After you set up the printer, print several test cards to determine how well the  laminator applies material to the card. You can print test cards from the Card  Printer Driver (refer to the printer’s Driver Guide), from the printer LCD panel  (refer to “Print a Test Card” on page 20), or from Printer Manager (refer to the  printer’s Installation and Administrator’s Guide). You may need to print multiple  test cards to make sure that the overlay is positioned correctly. The card stock, the  card design, and the printer’s environment all can affect the appearance of cards. When evaluating a card, make sure that: The overlays are being applied properly: • Each overlay is applied completely to the card. • The material adheres well to the edges of the card. • The overlay does not come off when the card is bent or twisted. • The card is debowed correctly. • The impression is positioned correctly and has the proper depth. • If you need to make adjustments to the laminator or overlay settings, refer to the  “Printer Manager” section of the printer’s Installation and Administrator’s Guide.  CD800 Card Printer User’s Guide A-11...
  • Page 110: Clear Laminator Card Jam

    Clear Laminator Card Jam Open the laminator access door. Remove the L1 and L2 (if installed) laminator cartridges.                                                                                                                           Turn the manual advance knobs inside of the laminator until the card is  accessible. Remove the card. Replace the laminator cartridges. Close the laminator access door. A-12 CLM Laminator...
  • Page 111: Clean The Laminator

    Clean the Laminator Clean the laminator when at least one laminator cartridge is loaded with  holographic overlay material and any of the following are true: Particles appear on the laminated cards. • Particles are visible inside the laminator. • For examples of problems that require laminator cleaning, refer to “Laminator  Problems” on page 56. This procedure uses a double‐sided, sticky cleaning card that removes holographic  overlay particles from the laminator. When you clean the CD system using a regular  cleaning card, the card also moves into the laminator and cleans the laminator  rollers, the card entry area, and the impresser exit rollers. This is sufficient if you  are not using holographic overlay. Refer to “Run a Cleaning Card” on page 32. Unlock the laminator access door and remove the L1 and L2 laminator  cartridges. Remove printed cards from the output  hopper, if necessary. Remove the protective paper from  both sides of the double‐sided, sticky  laminator cleaning card and insert the  card under the rollers of the card exit  slot of the laminator. When it is in the  correct location and pushed in far  enough, the card stays in place. CD800 Card Printer User’s Guide A-13...
  • Page 112 Use the LCD menu system to start the cleaning cycle. Ready Begin when the printer displays   and the U  button shows steady  green. Press the U  button.                                                               Suspended  displays on line 1 of the LCD panel. Press the E  key to enter the menu system. NTER                                                               Maintenance  displays on line 2 of the LCD panel. Press the E  key to  NTER Maintenance enter the   menu.                                                              Cleaning Card  displays on line 2 of the LCD panel. Press the E  key to  NTER Cleaning Card enter the   menu.                                                              Printer  displays on line 2 of the LCD panel. Press the down arrow.                                                              Laminator displays on line 2. Press the E  key. NTER                                                              A-14 CLM Laminator...
  • Page 113 Insert cleaning card  displays on the LCD panel. Press the U  button to  start the cleaning cycle.                                                              The laminator pulls the cleaning card from the card exit slot into the laminator  and moves it back and forth through the L1 and L2 cartridge areas, the card  entry area, and the exit rollers several times. If the system has locks, the used  card is ejected into the laminator reject tray. If the system does not have locks,  the used card is ejected into the laminator output hopper. Inspect the laminator cartridges for particles. If particles are present: Retrieve the laminator cleaning card and use it to remove the particles of  overlay material from the cartridges.  If particles still remain on the cartridge and inside of the laminator, use a  vacuum cleaner with a small plastic hose attachment to carefully remove  the particles. Also clean any remaining particles from the output hopper.  & T INTS If the cleaning card is not pulled into the laminator, the card is not in the  • correct position. The cleaning card must be located under the rollers of the  card exit slot inside the output hopper. At the end of the laminator cleaning cycle, the card can stick to the rollers in  • the output hopper. Pull on the card to remove it.  Discard the laminator cleaning card after one use. • Avoid contact with the heated roller, which contains sensitive electronic  • components. If cleaning the laminator does not solve the problem, contact your service  • provider for assistance. CD800 Card Printer User’s Guide A-15...
  • Page 114 A-16 CLM Laminator...
