C-4
Set up a Universal Serial Bus (US) port
1
2
3
4
5
6
7
Right-click on the My Computer icon on the desktop and then select Properties
from the popup menu. The System Properties dialog box appears.
Select the Device Manager tab to view a list of devices. (On Windows 2000, select
the Hardware tab and then click the Device Manager button.)
Select "View devices by type" if needed.
Click the + next to Universal Serial Bus controllers to display the USB port
controllers.
Click USB Root Hub, and then select the Properties button. (On Windows 2000,
right-click USB Root Hub and then select Properties from the pop-up menu.) The
USB Root Hub Properties dialog box appears.
Make sure that "Disable in this hardware profile" is not selected. Click OK to close
the dialog box.
Click the other entry, which includes the name of the installed USB device and
ends with "Host Controller", and then select the Properties button. (On Windows
2000, right-click USB Host Controller and then select Properties from the pop-up
menu.) The Properties dialog box appears.
– Make sure that "Disable in this hardware profile" is not selected.
– Click the Resources tab (see Figure C-2). The "Conflicting device list" should
show No conflicts.
Figure C-2: USB Root Hub Properties dialog box
If the Resources tab shows conflicts, select another configuration or change the
settings for the port, following port instructions.
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
