Advanced Controls
3
3 - 12 Enabling Other Displays
Extended Desktop Mode
The system supports Extended Desktop (the LCD and a monitor showing dif-
ferent views) in multiple display environments in Windows XP (this mode is
NOT supported in Windows 2000) . An Extended Desktop creates a desktop
spanning multiple displays and acts as a large workspace.
To get this effect:
1.
Attach your external monitor to the external monitor (VGA) port (or TV/
HDTV to the S-Video Out port), and turn it on.
2.
Go to the Advanced Display Settings (see
3.
Select the Displays tab (see
4.
Click the enable/disable button
to use (Monitor).
5.
Click Apply and an image will appear on the display device (give the
monitor a few seconds for the image to refresh).
6.
Click Yes to accept the settings and OK to save the changes.
7.
Use the Display Properties (see
select the second monitor
the "Display:" pop-up menu.
8.
Click "Extend my Windows desktop onto this monitor.".
9.
Click Apply > OK.
10. Use the Display Properties
drag the monitor icons to match the physical arrangement you wish to use.
Figure 3 - 3 on page 3 -
Figure 3 - 7 on page 3 -
/
for the display device you wish
Figure 3 - 9 on page 3 -
by clicking on the icon, or by selecting it from
2
(Figure 3 - 9 on page 3 -
5).
10).
13) window to
13) control panel to
