Planning Connectivity

PBX and ADU Connections

PBX and ADU
Connections
Dial-up The following diagram shows the dial-up connection between the
connection PBX and an ADU.
Legend
5-16 Issue 2 April 1996
1
5
1. PBX
2. Site-specific network connections
3. ADU
4. Proxy Agent PC
5. Digital-line circuit pack on PBX
6. Moss adapter
2
2
4
3
3 6
