Planning Connectivity

Cables and Connectors

Cables and Connectors
Materials To connect your PC to a modem, data module, or ADU, you need
needed the following cable:
If your cable does not have the appropriate gender connectors,
use a gender changer to make the correct cable configuration.
Serial I/O
To connect a certified UnixWare PC (using Serial I/O ports cards)
ports cards to a certified modem, data module or ADU, connect a Serial I/O
cable to a Serial I/O modular adapter.
See also For sample design configurations with Serial I/O cables and
adapters, see Appendix B.
Procedure Use the following steps to connect a certified PC that uses the
standard serial ports to a certified modem, data module, or ADU.
Communications
Hardware
modem
data module
ADU
Cable Connector
RS232 (M25B) PC end: 25-pin female
connector
Data module or modem
end: 25-pin male
connector
Moss adapter PC end: female
connector
Issue 2 April 1996
5-27
