Planning Connectivity
PC Hardware Connections
PC Hardware
Connections
PC
The following diagram shows PC hardware connections:
connections
Legend
1
2
3
1. The first serial port on the PC. Use the connection
described in either 2 or 3.
2. 25-pin male connector
3. 9-pin male connector and a 9- to 25-pin adapter
4. EIA232 cable
5. 25-pin female connector
6. Moss adapter
4
5
Issue 2 April 1996
2
6
7
5
5-25
