To Set the Dip Switch

To Set the Dip Switch
Introduction
You must verify that the dip switch is set correctly. If it is not, you
need to change the settings.
When to use
Set the dip switch after you have edited the Dialers file.
Settings for
The following table explains the settings for a 7400B data module.
the 7400B
data module
If the data
module is a ...
Stand alone, data-only
7400B data module
Voice-and-data
7400B data module
5-30 Issue 2 April 1996
Then do this...
Turn dip switch SW1 on.
Leave all other dip swltches off.
Leave all dip switches off.
