AT&T OneVision DEFINITY G3 Guide Installation And Connection Manual page 109

Planning Connectivity
To Set the Dip Switch
Settings for The following table shows the settings for the dip switches on a
a PDM PDM.
1.
Dip switch Setting
LOW OFF
300 OFF
1200 OFF
2400 OFF
4800 OFF
9600 ON
19.2 OFF
SPARE (none)
SPARE (none)
SPARE (none)
HDX OFF
SYNC OFF
INT OFF
DISC OFF
KYBD ON
The dip switch must be set at this option.
Dip switch
PRTY
I/OD
DMLL
MKBY
SPARE
1
SIGLS
AANS
DL-HI
CN25
CN18
RL21
CI12
PRTY
I/OD
DMLL
Setting
OFF
OFF
OFF
OFF
(none)
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Issue 2 April 1996
5-31
