Planning Connectivity

Proxy Agent and ADU Connections

Proxy Agent and ADU
Connections
Introduction The following diagram shows the connection between the Proxy
Agent PC and an ADU.
1
Legend
5-12 Issue 2 April 1996
2
3
1. PBX
2. Site-specific network connections
3. ADU
4. Proxy Agent PC
5. Moss adapter
6. Serial I/O modular adapter
7. Serial I/O cable
8. Serial I/O ports card
3
7
5
6
4
8
4
