AT&T OneVision DEFINITY G3 Guide Installation And Connection Manual page 201

Proxy Agent Administration
To Connect to a PBX
Testing Test the Proxy Agent software setup by connecting to each PBX.
connections
Step Action
3 Press
Ctrl-e
Result: The message line displays the time allotted for
the first attempt to connect. If the switch is available,
you usually see the login/password window in the first
few seconds. If you have an existing connection, the
Proxy Agent asks if you would like to disconnect from
the old connection.
Hint: You can abort the countdown by pressing
4 Enter the switch login and password.
Result: If you logged in successfully, the Main Menu
displays; otherwise, an error message or the system
prompt displays.
Notice that the menu shows you the:
Connected To system ID on the lower right
Active ID system ID on the up per right
The exit instructions are above the message line.
5 Save the switch login and password.
to save your work.
Ctrl-x
Issue 2 April 1996
.
End
9-21
