Constraining Factors
This section describes the constraining factors that limit the capabilities
supplied in the table above.
Calling Groups
Members of groups . QCCs cannot be members of calling groups because
the QCC position is set up as a system operator and has its own queue that
is different from the group's queue.
Carriers
The first slot of the basic carrier is used for the processor module.
Coverage Groups
Senders per group . QCCs cannot be senders because they do not have
coverage available and use Position-Busy instead.
CTI Link
One CTI link is supported in Hybrid/PBX mode only.
Fax machines with Message-Waiting
The system can support more than 16 fax machines, but those in excess of
16 cannot use fax message-waiting indication.
System Operator Consoles
DLCs . Two consoles are allowed for each MLX or analog module, with a
maximum of eight per system. Up to two DSSs can be attached to an MLX
operator console, and one is built into the MERLIN II System Display
Console.
QCCs . Two consoles are allowed for each MLX module with a maximum of
four per system.
Ports (not simultaneously)
Voice-Mail interface . Although the system software supports up to 24 VMI
ports, all the VMI ports must be in the same calling group, and the
maximum number of extension in a calling group is 20.
Speed Dial
Personal Speed Dial . Single-line and 5- or 10-button telephones only.
System Programming Equipment
Remote access overrides on-site programming except during backup or
restore.
Telephones (not simultaneously)
Analog multiline with/without Voice Announce to Busy . 17 slots x 8
ports/board.
MLX-20L . RAM limit and the total includes the MLX-20L telephone used for
system programming.
All other MLX telephones . RAM limit. An MFM and a ISDN terminal adapter
cannot be connected to the same telephone (including the MLX-20L) at the
same time.
Single-line . RAM limit
Power failure transfer . 1 for each 4 LS/GS line/trunk jacks.
Traffic (100 call seconds/hr/system)
Assumes 20 percent internal traffic.
Two-party conversations
216 time slots.
