Labeling The Extension - AT&T MERLIN LEGEND Release 3.1 Installation Manual

Assembling MLX Telephones
Figure 3–33. Labeling the Extension
b Type or write the assigned extension number on the card. See Figure
3–33.
c If you are wall-mounting an MLX-10, MLX-10D, or MLX-10DP telephone, go
to Step 5. If you are assembling a desk telephone, go to Step 6.
3–52
Installing Telephones and Adjuncts
555-1234
MLX-10
Volume ABC DEF
1 2 3
Feature Transfer GHI JKL MNO
4 5 6
HFAI Conf
PQRS TUV WXYZ
7 8 9
Mute
Drop
Oper
#
*
0
Hold
Speaker
