Connecting a Printer to the Control Unit
Connecting a Printer Within 50 Feet (15.2 m)
If the printer is within 50 ft. (15.2 m) of the control unit and is connected to the
same 117-V AC branch as the control unit, use this procedure to connect a
printer to the control unit.
You need the following hardware for this procedure:
Z200A EMI filter
Adapter for the connector on the interface cable
355A for a male connector
355AF for a female connector
Installing the PC, CAT, or Printer
5–15
