Installing Multi-Function Modules
MFM
Module
Cover
Locating
Slot
Figure 3–6. Releasing the Module Cover
b Press the center of the right side of the module cover with one hand to
release the locking tab.
c Swing open the module cover to release it from the left side locating slot.
3–8
Installing Telephones and Adjuncts
Pull Up and Away
Press
Center Tab
to Release
