Installing Multi-Function Modules
Figure 3–13. Lowering and Locking the Module Cover
b Lower the cover to the right and press firmly into the center slot to lock the
tab in place. The tab must be secure.
Lower and
Press Into
Center Slot
to Secure
Installing Telephones and Adjuncts
3–15
