Analog Voice and Modem Data Stations
If you are not sure, see the customer's system manager or the documentation
packaged with the modem, data communications software, and data terminal.
3 Connect the modem to the GPA.
a Plug one end of a D4BU cord into the TEL/EQUIP jack on the GPA.
b Plug the other end into the modem as indicated in the modem's
documentation.
4 Connect the GPA to the analog multiline telephone.
a Plug one end of a D8AC cord into the VT jack on the back of the GPA.
b Plug the other end into the OTHER jack on the bottom of the telephone.
c Slide the switch on the back of the GPA to Automatic or Basic. See "GPA
Settings" above for your options.
5 Use a D8W cord to connect the STATION jack on the BR-241-B1 bridging
adapter to the LINE jack on the analog multiline telephone.
6 Use two D8W cords to connect the EVEN and ODD jacks on the
BR-241-B1 bridging adapter to the extension jacks indicated on Form 2a,
System Numbering: Extension Jacks.
Connect the EVEN jack on the bridging adapter to the extension jack that is
associated with the even-numbered extension, not the logical ID.
7 Connect all power cords to an AC outlet that is not controlled by a wall
switch.
6–6
Connecting Data Equipment
