Installing Multi-Function Modules
Press
Center Tab
Figure 3–3. Releasing the Deskstand
2 Release and remove the deskstand from the telephone. See Figure 3–3
and Figure 3–4.
a Press on the top rear center of the deskstand to release the tab.
b Pull the deskstand up toward you and swing away from the telephone.
Pull Up
and
Away
Installing Telephones and Adjuncts
3–5
