Video Conferencing Data Stations
Video Conferencing Data Stations
You can use the terminal adapter with a Multipurpose Enhancement Board for
synchronous data communication. This type of station allows data
transmission at speeds of 56 or 64 kbps.
This section is only a guideline for connecting video conferencing equipment
to the system. For additional information, refer to the documentation
packaged with the video codec.
Also, for instructions on using the Multipurpose Enhancement Board or for
additional information on setting up the terminal adapter, see the
documentation packaged with the terminal adapter.
You need the following hardware:
008 MLX module or 408 GS/LS-MLX module and a 100D module in the
control unit
ACCULINK 3150 CSU
Two terminal adapters:
–
Two 7500B data modules with two 7500B data module feature
package 2 upgrades (user manuals included)
–
Two ExpressRoute terminal adapters
Two Multipurpose Enhancement Boards [install one of these in each
terminal adapter for synchronous communication and an RS-366
Automatic Calling Unit (ACU) interface]
Two WP901 10-L7 power supplies (one per stand-alone terminal
adapter)
Two 440A4 terminating resisting adapters
Z77A multiple mounting (mounting for multiple 7500B data modules)
PictureTel video codec unit
Connecting Data Equipment
6–17
