MLX Voice and Modem Data Stations
MLX Voice and Modem
Data Stations
Figure 6–3 shows the equipment configuration for an MLX voice and modem
data station.
AC Outlet
Figure 6–3. Modem Data and MLX Voice Equipment Configuration
6–10
Connecting Data Equipment
008 MLX or
408 GS/LS-MLX
Module
MLX
Extension
jack
CAUTION
TURN OFF
POWER BEFORE
INSERTING OR
REMOVING
MODULES
D8W cord
LINE jack
MLX-20L
Home
More
Menu
Inspct
v
v
Volume
Feature
Transfer
HFAI
Conf
Mute
Drop
Speaker
Hold
Data Terminal
MLX Telephone
with MFM
EIA-232-D Cable
SERIAL
connector
TEL/OTHER
D4BU
jack
cord
LINE jack
Modem
