4.
Attach a data cable from a SATA connector on the system board to the hard drive, and attach the
fifth drive power cable to the drive.
Figure 4-42

Processor heatsink

Removing the CPU heatsink

NOTE
workstation. Be aware that different variations of the CPU heatsinks exist, but the overall
procedures listed are sufficient to assist you in removing the CPU heatsink.
1.
Shut down the workstation, and disconnect power from the system (
procedures on page
workstation on its side with the system board facing up.
88
Chapter 4 Removal and replacement procedures
Attaching the data cable for the SATA hard drive in the fifth hard drive bay
The following illustrated CPU heatsink is typical of what you might have in your
55). Remove the access panel
Pre-disassembly
(Access panel on page
60), and place the
ENWW
