Preventing electrostatic damage to equipment

Many electronic components are sensitive to ESD. Circuitry design and structure determine the degree
of sensitivity. The following packaging and grounding precautions are necessary to prevent damage to
electric components and accessories.
Transport products in static-safe containers, such as tubes, bags, or boxes, to avoid hand contact.
Protect all electrostatic parts and assemblies with conductive or approved containers or packaging.
Keep electrostatic-sensitive parts in their containers until they arrive at static-free stations.
Place items on a grounded surface before removing them from their containers.
When handling or touching a sensitive component or assembly, ground yourself by touching the
chassis.
Avoid contact with pins, leads, or circuitry.
Place reusable electrostatic-sensitive parts from assemblies in protective packaging or conductive
foam.

Personal grounding methods and equipment

Use the following equipment to prevent static electricity damage to equipment:
Wrist straps are flexible straps with a maximum of one megohm ± 10% resistance in the ground
cords. To provide a proper ground, wear the strap against bare skin. The ground cord must be
connected and fit snugly into the banana plug connector on the grounding mat or workstation.
Heel straps, toe straps, and boot straps can be used at standing workstations and are compatible
with most types of shoes or boots. On conductive floors or dissipative floor mats, use them on both
feet with a maximum of one-megohm ± 10% resistance between the operator and ground.
Table 4-2
Static shielding protection levels
Method
Antistatic plastic
Carbon-loaded plastic
Metallized laminate

Grounding the work area

To prevent static damage at the work area:
Cover the work surface with approved static-dissipative material. Provide a wrist strap connected
to the work surface and properly grounded tools and equipment.
Use static-dissipative mats, foot straps, or air ionizers to give added protection.
Handle electrostatic sensitive components, parts, and assemblies by the case or PCB laminate.
Handle them only at static-free work areas.
Turn off power and input signals before inserting and removing connectors or test equipment
Use fixtures made of static-safe materials when fixtures must directly contact dissipative surfaces.
ENWW
Voltage
1,500
7,500
15,000
Service considerations
51
