10.
Lift the system board up to disengage it from the connectors, slide it away from the power supply,
and then lift it up and out of the chassis.
Figure 6-53
To install the system board, reverse the removal procedure.
CAUTION:
with the rotation of the drive cage or power supply.
72
Chapter 6 Removal and Replacement Procedures
Removing the System Board
When reconnecting the cables it is important that they be positioned so they do not interfere
