3.
Replace the four screws on top of the drive cage that secure the hard drive in the bay.
NOTE:
that the screw holes on the hard drive are properly aligned with the screw holes on the drive cage.
Figure 6-44
4.
Connect the data cable (1) and power cable (2) to the back of the primary hard drive.
NOTE:
system board to avoid any hard drive performance problems.
Figure 6-45
CAUTION:
sharp bend can break the internal wires.
5.
Return the drive cage to the down position.
6.
Replace the computer cover.
66
Chapter 6 Removal and Replacement Procedures
You must hold the hard drive in place with one hand while installing the screws to ensure
Replacing the Hard Drive Retainer Screws
The data cable must be connected to the dark blue connector labeled SATA 0 on the
Connecting the Hard Drive Data and Power Cables
Never crease or bend a SATA data cable tighter than a 30 mm (1.18 in) radius. A
