Figure 6-27
Item
1
2
The serial port jumpers on the powered serial port expansion card are located as shown in the following
illustration:
Figure 6-28
Item
1
2
54
Chapter 6 Removal and Replacement Procedures
Serial Port Jumper Locations on the System Board
Jumper
P16
P17
Powered Serial Port Expansion Card Jumper Locations
Jumper
J4
J5
Port Name
COM 1
COM 2
Port Name
COM 3
COM 4
