RAID Support
The Intel
SATA controller that supports both 1.5 and 3.0 Gbps data transfer rates. The Intel
System SR1560SF (product code SR1560SFHS) provides SAS and SATA support. Both
systems can be configured for RAID 0, 1, and 10.
The Intel
®
Intel
RAID Activation Key AXXRAKSW5 accessory.
For information on configuring RAID, see the RAID software user's guide that is
included on the Intel
Front of Server System
Standard Control Panel
The diagram below shows the features of the standard control panel.
Callout
A.
B.
C.
D.
®
Intel
Server System SR1560SF Service Guide
®
Server System SR1560SF (product code SR1560SF) provides an embedded
®
Server System SR1560SF can be configured for SW RAID 5 by using the
®
Server Deployment Toolkit 2.0 CD.
Feature
NIC 2 Activity LED
Continuous green light indicates a link between the system and
the network to which it is connected.
NIC 1 Activity LED
Blinking green light indicates network activity.
Power/Sleep Button
Powers on/off the system.
Puts the system in an ACPI sleep state.
Power/Sleep LED
Continuous green light indicates the system has power applied to
it.
Blinking green indicates the system is in S1 sleep state.
No light indicates the power is off / is in ACPI S4 or S5 state.
A
B
C
D
E
F
L
K
J
G
H
I
AF002189
Function
®
Server
15
