3
Hardware Installations and
Upgrades

Before You Begin

Before working with your server product, pay close attention to the
at the beginning of this manual.
Note: Whenever you service the system, you must first power down the server and unplug all
peripheral devices and the AC power cord.

Tools and Supplies Needed

•
Phillips* (cross head) screwdrivers (#1 bit and #2 bit)
•
Antistatic wrist strap and conductive foam pad (recommended)

System References

All references to left, right, front, top, and bottom assume the reader is facing the front of
the server system as it would be positioned for normal operation.

Removing and Installing the Front Bezel

The front bezel is available as an optional accessory for the Intel
SR1560SF. Bezel product code: ADWBEZBLACK.
"Safety Information"
®
Server System
