Appendix A: Technical Reference

600W Single Power Supply Input Voltages

•
100-127V at 50/60 Hz; 8.55 A max.
•
200-240V at 50/60 Hz; 4.3 A max.

System Environmental Specifications

Temperature
Non-operating
Operating
Humidity
Non-operating
Shock
Operating
Unpackaged
Packaged
Acoustic noise
Electrostatic
discharge (ESD)

Table 5. System Environmental Specifications

-40 ° to +70 °C.
10° C to 35° C (50° F to 90° F) with the maximum rate of change not to
exceed 10° C per hour
90% relative humidity (non-condensing) at 28 °C.
2.0 g, 11 msec, 1/2 sine
Trapezoidal, 25 g, velocity change 136 inches/sec (40 lbs to > 80 lbs)
Non-palletized free fall at a height of 24 inches (40 lbs to > 80 lbs)
Sound Pressure: 55 dBA (rack mount) in an idle state at typical office
ambient temperature. (23 +/- degrees C) Sound Power: 7.0 BA in an idle
state at typical office ambient temperature. (23 +/- 2 degrees C).
+/-15kV except I/O port +/-8KV, per Intel Environmental Test Specification.
