System Rear

Except for the shared AC power supply, each server board has its own back panel
connectors.
A.
B.
C.
D.
The LEDs at the right and left of each NIC provide the following information.
LED
Left
Right
6
A
D
AC power connector (one per
system)
PCI Express* add-in card slot
location (one for each server board)
NIC 1 (10 / 100 / 1000 Mb) (one for
each server board)
Video connector (one for each server
board)

Figure 3. Back Panel Connectors

Table 3. NIC LED Descriptions

LED State
Off
Solid amber
Blinking amber
Off
Solid amber
Solid green
B C
E F G
E. Serial port (one for each server
board)
F. NIC 2 (10 / 100 / 1000 Mb) (one for
each server board)
G. USB ports 0-1 (one sets of two ports
for each server board)
No network connection
Network connection in place
Transmit/receive activity
10 Mbps connection (if left LED is on or blinking)
100 Mbps connection
1000 Mbps connection
®
Intel
B C
D
E F G
AF002496
Description
Server System SR1520ML User's Guide
