Clearing the Password

If the user or administrator password(s) is lost or forgotten, moving the password clear
jumper into the "clear" position clears both passwords. The password clear jumper must
be restored to its original position before a new password(s) can be set.
1. Power down the system and disconnect the AC power.
2. Open the server chassis.
3. Move the J6B1 Password Clear jumper from the normal operation position,
Password Clear Protect, at pins 1 and 2 to the Password Clear Erase position,
covering pins 2 and 3 as indicated in the following diagram.
4. Reconnect the AC power and power up the system.
5. Power down the system and disconnect the AC power.
6. Return the J6B1 Password Clear jumper to the Password Clear Protect position,
covering pins 1 and 2.
64

Figure 47. Password Clear Jumper in Clear Password Position

Password
Default
Clear
2
CLEAR
J6B1
Password
3
AF002605
®
Intel Server System SR1520ML User's Guide
