Table 6-3. Port Detailed Statistics Fields (continued)
Field
Packets Transmitted 64
Octets
Packets Transmitted 65-
127 Octets
Packets Transmitted 128-
255 Octets
Packets Transmitted 256-
511 Octets
Packets Transmitted 512-
1023 Octets
Packets Transmitted
1024-1518 Octets
Packets Transmitted
1519-1522 Octets
Total Packets Transmitted
Successfully
Unicast Packets
Transmitted
Multicast Packets
Transmitted
Broadcast Packets
Transmitted
Total Transmit Errors
Tx FCS Errors
Tx Oversized
Monitoring the System
GS108T and GS110TP Smart Switch Software Administration Manual
Description
The total number of packets (including bad packets) transmitted that were 64
octets in length (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 65 and 127 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 128 and 255 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 256 and 511 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 512 and 1023 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 1024 and 1518 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 1519 and 1522 octets in length inclusive (excluding framing bits but
including FCS octets).
The number of frames that have been transmitted by this port to its segment.
The total number of packets that higher-level protocols requested be
transmitted to a subnetwork-unicast address, including those that were
discarded or not sent.
The total number of packets that higher-level protocols requested be
transmitted to a Multicast address, including those that were discarded or not
sent.
The total number of packets that higher-level protocols requested be
transmitted to the Broadcast address, including those that were discarded or
not sent.
The sum of Single, Multiple, and Excessive Collisions.
The total number of packets transmitted that had a length (excluding framing
bits, but including FCS octets) of between 64 and 1518 octets, inclusive, but
had a bad Frame Check Sequence (FCS) with an integral number of octets
The total number of frames that exceeded the max permitted frame size. This
counter has a max increment rate of 815 counts per second at 10 Mb/s.
