Configuring QoS on Interfaces
S e n d f e e d b a c k t o n x 5 0 0 0 - d o c f e e d b a c k @ c i s c o . c o m
Command
Step 6
switch(config-pmap-c) priority
Step 7
switch(config)# interface {ethernet
slot/port | port-channel channel-number}
Step 8
switch(config-if)# service-policy input
policy-name
The following example shows that the system class best-effort-drop-class is guaranteed 20 percent of the
bandwidth on interface ethernet 1/1:
switch(config)# class-map best-effort-drop-class
switch(config-cmap)# match cos 5
switch(config)# policy-map policy1
switch(config-pmap)# class best-effort-drop-class
switch(config-pmap-c)# bandwidth percent 20
switch(config)# interface ethernet 1/1
switch(config-if)# service-policy input policy1

Configuring Egress Policies

An egress policy is a service policy applied to the outgoing traffic on an Ethernet interface. You can
configure an egress policy to guarantee the bandwidth for the specified traffic class or to configure the
egress queues.
To configure an egress policy, perform this task:
Command
Step 1
switch# configure terminal
Step 2
switch(config)# class-map class-name
Step 3
switch(config)# policy-map policy-name
Step 4
switch(config-pmap)# class class-name
Step 5
switch(config-pmap-c) bandwidth percent
percentage
Step 6
switch(config-pmap-c) priority
Step 7
switch(config)# interface {ethernet
slot/port | port-channel channel-number}
Step 8
switch(config-if)# service-policy output
policy-name
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
31-14
Purpose
(Optional) Specifies that ingress traffic in this class is
mapped to a strict priority queue.
Enters configuration mode for the specified interface.
The service policy on a port channel applies to
Note
all member interfaces.
Applies the policy map to the interface.
Purpose
Enters configuration mode.
Defines a class name for the egress policy.
Creates a policy map to specify the QoS parameters
for the egress policy.
Associates the egress class with this policy and enters
configuration mode for the class.
Specifies the guaranteed percentage of bandwidth
allocated to this class.
Specifies that egress traffic in this class is mapped to
a strict priority queue.
Enters configuration mode for the specified interface.
Note The service policy on a port channel applies to
all member interfaces.
Applies the policy map to the interface.
Chapter 31 Configuring QoS
