NOTE: Depending on your server, this page might look slightly different.
Figure 8-27 Current LDAP Parameters Page
NOTE:
The BL c-Class tab is available only on HP Integrity server blades.
Table 8-28 lists the fields and descriptions.
Table 8-28 Current LDAP Parameters Page Description
Field
Directory Authentication
Local User Accounts
Directory Server IP Address
Directory Server LDAP Port
Distinguished Name
User Search Contexts (1,2,3)
Choosing enable or disable, activates or deactivates directory support on iLO 2:
• Enable with Extended Schema: selects directory authentication and authorization
using directory objects created with HP schema. Select this option if the directory
server has been extended with the HP schema.
• Enable with Default Schema: selects directory authentication and authorization
using user accounts in the directory which has not been extended with the HP
schema. User accounts and group memberships are used to authenticate and
authorize users. Data in the Group Administration page must be configured after
this option is selected.
Includes or excludes access to local iLO 2 user accounts. Locally-stored user accounts
can be active while LDAP directory support is enabled. If local user accounts are
enabled, you may log in to the iLO 2 using locally-stored user credentials. If they are
disabled, access is limited to valid directory credentials only.
IP address of the directory server.
Port number for the secure LDAP service on the server. The default value for this port
is 636.
Distinguished Name of iLO 2, specifies where this iLO 2 instance is listed in the directory
tree.
Example: cn=MP Server,ou=Management Devices,o=hp
User name contexts are used to locate an object in the tree structure of the directory
server and applied to the login name entered to access iLO 2.
Description
